ASTM B152 C11000,C12200,EN 1652,EN 1758,SEMI G4-0302 Copper Sheet/Strips/Tape

copper-tapes
  • copper-tapes
  • 30-Meters-Single-Side-Conductive-Copper-Foil-Tape-Strip-Adhesive-EMI-Shielding-Heat-Resist-Tape
  • ASTM B152 C11000,C12200,EN 1652,EN 1758,SEMI G4-0302 Copper Sheet/Strips/Tape
  • High Elongation HTE Rolled Annealed Copper Foil 0.035mm High Thermal Endurance-01
  • single_side_type_copper_foil_sheet_18_micron_width_530_mm_with_high_peel_strength
  • ASTM B152 C11000,C12200,EN 1652,EN 1758,SEMI G4-0302 Copper Sheet/Strips/Tape
  • Colored-Foil-Various
  • ASTM B152 C11000,C12200,EN 1652,EN 1758,SEMI G4-0302 Copper Sheet/Strips/Tape
  • ASTM B152 C11000,C12200,EN 1652,EN 1758,SEMI G4-0302 Copper Sheet/Strips/Tape
  • ASTM B152 C11000,C12200,EN 1652,EN 1758,SEMI G4-0302 Copper Sheet/Strips/Tape
Model No.︰-
Brand Name︰ASTM B152,ASTM B36,ASTMB B103,ASTM B122 VLP-HTE-HF
Country of Origin︰-
Unit Price︰-
Minimum Order︰-
Share on:

 Total 10 Related Items
Prev678910

Product Description

 Copper Sheet/Strips/foil


JIS H3100 COPPER AND COPPER ALLOY SHEETS,PLATES AND STRIPS
ASTM B36/B36M STANDARD SPECIFICATION FOR BRASS,PLATE,SHEET,STRIP AND ROLLED BAR
DIN EN 1652 COPPER AND COPPER ALLOYS PLATE,SHEET,STRIP AND CIRCLES FOR GENERAL PURPOSES
DIN EN 1758 COPPER AND COPPER ALLOYS STRIP FOR LEADFRAMES
SEMI G4-0302 SPECIFICATION FOR INTERGRATED CIRCUIT LEADFRAME MATERIALS USED IN THE PRODUCTION OF STAMPED LEADFRAMES


 Product Ranges of copper strip and brass strip


Copper plate and strip ISO US Japan UK Germany GB
(ISO) (ASTM) (JIS) (BS) (DIN)
Cu-ETP C11000 C1100 C101 R-Cu57 T2
Cu-DHP C12200 C1220 C106 Sf-Cu TP2

Brass plate and strip ISO US Japan UK Germany
(ISO) (ASTM) (JIS) (BS) (DIN)
CuZn10 C22000 C2200 CZ101 CuZn10 H 90
CuZn30 C26000 C2600 CZ106 CuZn30 H 70
          H 68
CuZn35 C26800 C2680 CZ107 CuZn36 H 65
          H 62

Bronze plate and strip ISO US Japan UK Germany GB
(ISO) (ASTM) (JIS) (BS) (DIN)
CuSn6 C51900 C5191 PB103 CuSn6 QSn6.5-0.1
          QSn6.5-0.4
CuSn4 C51100 C5111 PB101 CuSn4 QSn4-0.3
CuSn8 C52100 C5212 PB104 CuSn8 QSn8-0.3

Nickel silver plate and strip ISO US Japan UK Germany GB
(ISO) (ASTM) (JIS) (BS) (DIN)
CuNi15Zn21 C75400   NS105   BZn15-20
CuNi18Zn20 C75200 C7521 NS106 CuNi18Zn20 BZn18-18
CuNi18Zn27 C77000 C7701 NS107 CuNi18Zn27 BZn18-26

 Copper Tape

Copper Tape consists of a copper foil backing and pressure sensitive acrylic adhesive. The copper foil backing is extremely malleable and accepts solder, making it suitable for a broad range of industrial and electrical applications. The tape comes in both conductive and non-conductive acrylic adhesives and both are very aggressive and deliver excellent adhesion. This combination of backing and adhesive makes this tape an ideal choice for EMI/RFI shielding and static discharge applications including printed circuit board manufacture and repair. It is also supplied on a removable paper liner for easy handling and die-cutting.

Copper Tape Applications

Copper tape has many uses including EMI shielding, arts and crafts, paper circuits, electrical repairs and grounding. It also acts as a repellent for slugs and snails to keep plants, flowers and vegetables safe. When large surfaces are to be shielded, it is recommended to cover most of the surface with copper foil.

Copper Tape for EMI/RFI Shielding:
Electromagnetic interference (EMI) shielding is used in electrical parts to reduce the electromagnetic induction in a field. Copper foil tape is usually used to block the field as it is one of the finest magnetic materials. Many factors influence the actual effectiveness of an EMI/RFI shielding tape after it has been applied, such as the type and thickness of foil, type of adhesive, closeness of contact, smoothness of application surface, strength, and frequency of the EMI/RFI signal, etc.

Guitar Shielding:
Avoid interference caused by ineffective conductive shielding paint. Use to shield the pickup and control cavities of a guitar. Perfect solution for EMI, EMF & RFI shielding.

ARTS & CRAFTS:
Great for stained glass window making, scrapbooking, outdoor garden and home interior decorations.

Product Image

copper-tapes
copper-tapes

30-Meters-Single-Side-Conductive-Copper-Foil-Tape-Strip-Adhesive-EMI-Shielding-Heat-Resist-Tape
30-Meters-Single-Side-Conductive-Copper-Foil-Tape-Strip-Adhesive-EMI-Shielding-Heat-Resist-Tape


High Elongation HTE Rolled Annealed Copper Foil 0.035mm High Thermal Endurance-01
High Elongation HTE Rolled Annealed Copper Foil 0.035mm High Thermal Endurance-01

single_side_type_copper_foil_sheet_18_micron_width_530_mm_with_high_peel_strength
single_side_type_copper_foil_sheet_18_micron_width_530_mm_with_high_peel_strength


Colored-Foil-Various
Colored-Foil-Various
