Model No.︰ISO 2531
Brand Name︰ISO 2531,EN545,EN598,AS 2280 DUCTILE IRON PIPE
Country of Origin︰-
Unit Price︰US $ 440 / MT
Minimum Order︰50 MT
Share on:

 Total 7 Related Items
12345Next

Product Description

Centrifugal ductile cast iron pipes are ideal pipes for municipal administration, industrial and mining enterprises, urban water supply and gas pipe networks. Centrifugal ductile cast iron pipes feature high intensity, good elasticity, corrosion resistance and simple installation, have the intrinsic quality of iron and the performance of steel, and are updated products of the traditional cast iron pipes and common steel pipes; the company can annually produce more than 200,000 tons of various ductile cast iron pipes with the specifications of DN100-1,600mm and various interface types such as T type, K type, N1 type and S type.

Weight of T-shaped Ductile Cast Iron Pipe (K9-class, standard effective length of 6m)

Nominal diameter DN(mm)

Outer diameter DE (mm)

Wall thickness e (mm)

Weight per meter (Kg/m)

Bell mouth weight(approximate value) (Kg)

Total weight(approximate value) (Kg)

80

98

12.2

3.4

76.5

100

118

6.1

15.1

4.3

95

125

144

6.2

18.9

5.7

119

150

170

6.3

22.8

7.1

144

200

222

6.4

30.6

10.3

194

250

274

6.8

40.2

14.2

255

300

326

7.2

50.8

18.9

323

350

378

7.7

63.2

23.7

403

400

429

8.1

75.5

29.5

482

450

480

8.6

89.3

38.3

575

500

532

104.3

42.8

669

600

635

9.9

137.3

59.3

882

700

738

10.8

173.9

79.1

1123

800

842

11.7

215.2

102.6

1394

900

945

12.6

260.2

129.6

1691

1000

1048

13.5

309.3

161.3

2017

1100

1152

14.4

362.8

194.7

2372

1200

1255

15.3

420.1

237.7

2758

1400

1462

17.1

547.2

279.3

3563

1600

   1668

   18.9

690.3

526.2

4668

Manufacturing Standard For Ductile iron pipes
ISO 2531 Ductile iron pipes, fittings, accessories and their joints for water or gas application

EN 545 Ductile iron, pipes, fittings, accessories and their joints for water pipelines -Requirements and test methods

EN 598 Ductile iron pipes, fittings, accessories and their joints for sewerage application - Requirements and test methods

EN 877 Cast iron pipes and fittings, their joints and accessories for the evacuation of water from buildings - Requirements, test methods and quality assurance

EN 969 Ductile iron pipes, fittings accessories and their joints for gas pipelines - Requirements and test methods

EN 12842  Ductile iron fittings for PVC-U or PE piping systems - Requirements and test methods

BS 4772-1988 Specification for ductile iron pipes and fittings

ISO 7186-2011 Ductile iron products for sewerage applications
ISO8179 standard for zinc spraying
Coating with metallic zinc which contains zinc at least 99.99%. The thickness of zinc coating is not less than 130g/m2
ISO 4179 standard for cement mortar lining

AS/NZS 2280 Ductile Iron Pipes and Fittings
