Product Description

Galvanized Coils/Sheets
Metals International's continuous hot-dip galvanizing coils or sheets has been constructed with world advanced technology.Typical steel grade produced are SGCC and SGCD. At present, we can provide it  in accordance with the international standards such as JIS, DIN and ISO (SZ stands for Zn-Al alloy steel, containing 5% Al in coated layer, equal to GF grade) and DIN EN standards to make products in type of CQ-SEDDQ, HSS-CQ-DDQ, BH, DP. Surface treatment includes passivation, finger print resistance and oiling.

Process flow of the line: 1.Full hard cold rolled coil - cleaning - annealing in a continuous horizontal furnace - dip galvanizing in the molten zinc pot (GI or SZ) - air knife - skin pass - stretcher leveling - chromic acid passivation/black resistance - oiling - coiling.

or 2.Full hard cold rolled coil - cleaning with electrolytic process - annealing in a vertical furnace - zinc pot (GI or GA pot) - alloying furnace - cooling tower - intermediate looper - skin pass - stretcher leveling - chromic acid passivation/finger print resistance - oiling - coiling

The products  are all zero spangle type with super property, beautifully evenly zinc coating, excellent corrosion resisting performance and process properties. They can be widely used in industries such as buildings, household electrical appliances, automobile, vessel and package, meanwhile, the products are good base materials for coating.
Remarks:
Tolerance for thickness, width, flatness ect, can conform to the individual product specification.
Coil inside diameters can be either 508mm or 610mm,maximum coil outside diameter is 2000mm.
Weight of a single coil can be from 3 to 25 metric tons.
Please make enquires to our Sales& Marketing Division for products with special specifications.

STANDARD

STEEL GRADE

EN10142/EN10147/

EN10292

DX51D+Z,DX52D+Z,DX53D+Z,DX54D+Z,DX56D+Z,

S220GD+Z,S250GD+Z,S280GD+Z,S320GD+Z,S350GD+Z,

S550GD+Z,H220PD+Z,H260PD+Z,H300LAD+Z,H340LAD+Z,

H380LAD+Z,H420LAD+Z,H180YD+Z,H220YD+Z,H260YD+Z,

H180BD+Z,H220BD+Z,H260BD+Z,H260LAD+Z,H300PD+Z,

H300BD+Z,H300LAD+Z

JIS G3302

SGCC,SGHC,SGCH,SGCD1,SGCD2,SGCD3,SGCD4,SGC 340,

SGC 400,SGC 440,SGC 490,SGC 570,SGH 340,SGH 400,

SGH 440,SGH 490,SGH 540

ASTM

A653 CS Type A,A653 CS Type B,A653 CS Type C,A653 FS Type A,A653 FS Type B,,A653 DDS Type A,A653 DDS Type C,

A653 EDDS,A653 SS230,A653 SS255,A653 SS275

A653 SS340 Class 1/2/3/4,A653 SS550 Class 1/2,

A653 HSLAS 275/340/410/480/550,

A653 HSLAS-F 275/340/410/480/550,

A653 SHS 180/210/240/280/300,

A653 BHS 180/210/240/280/300,

A526,A527,A528,A446 Grade A/B/C/D/E/F.

Q/BQB 420

DC51D+Z,DC52D+Z,DC53D+Z,DC54D+Z,DC56D+Z,St01Z,

St01ZR,St02Z,St02ZR,St03Z,St04Z,St05Z,St06Z,St07Z,

StE280-2Z,Ste345-2Z,HSA340Z,HSA410Z,HSA340ZR,

HSA410ZR.







Thickness (mm)

Width(mm)

0.3

900

1050

1250

1450

1575

0.4

900

1050

1250

1450

1575

0.5

900

1050

1250

1450

1575

0.6

900

1050

1250

1450

1575

0.7

900

1050

1250

1450

1575

0.8

900

1050

1250

1450

1575

0.9

900

1050

1250

1450

1575

1

900

1050

1250

1450

1575

1.2

900

1050

1250

1450

1575

1.5

900

1050

1250

1450

1575

1.8

900

1050

1250

1450

1575

2

900

1050

1250

1450

1575

2.2

900

1050

1250

1450

1575

2.5

900

1050

1250

1450

1575



Specification Zinc coating Material   Specification Zinc coating Material
0.25*1000*C 80 DX51D+Z 0.4*1250*C 80 DX51D+Z
0.3*1000*C 80 DX51D+Z 0.42*1250*C 80 DX51D+Z
0.35*1000*C 80 DX51D+Z 0.45*1250*C 225 S280GD+Z
0.4*1000*C 80 DX51D+Z 0.47*1250*C 225 S280GD+Z
0.5*1000*C 80 S280GD+Z 0.5*1250*C 80 SGCC
0.5*1000*C 80 DX51D+Z 0.55*1250*C 180 S280GD+Z
0.58*1000*C 80 DX51D+Z 0.55*1250*C 225 S280GD+Z
0.6*1000*C 80 DX51D+Z 0.6*1250*C 80 DX51D+Z
0.7*1000*C 80 DX51D+Z 0.65*1250*C 180 DX51D+Z
0.75*1000*C 80 DX51D+Z 0.7*1250*C 80 DX51D+Z
0.8*1000*C 80 DX51D+Z 0.7*1250*C 80 SGCC
0.8*1000*C 80 DX53D+Z 0.75*1250*C 80 DX51D+Z
0.85*1000*C 80 DX51D+Z 0.8*1250*C 80 DX51D+Z
0.9*1000*C 80 DX51D+Z 0.9*1250*C 80 DX51D+Z
0.98*1000*C 80 DX51D+Z 0.95*1250*C 80 DX51D+Z
0.95*1000*C 80 DX51D+Z 1.0*1250*C 80 DX51D+Z
1.0*1000*C 80 DX51D+Z 1.15*1250*C 80 DX51D+Z
1.1*1000*C 80 DX51D+Z 1.1*1250*C 80 DX51D+Z
1.2*1000*C 80 DX51D+Z 1.2*1250*C 80 DX51D+Z
1.2*1050*C 150 CSB 1.35*1250*C 80 DX51D+Z
1.4*1000*C 80 DX51D+Z 1.4*1250*C 80 DX51D+Z
1.5*1000*C 80 DX51D+Z 1.5*1250*C 80 DX51D+Z
1.55*1000*C 180 S280GD+Z 1.55*1250*C 80 DX51D+Z
1.55*1000*C 180 S350GD+Z 1.6*1250*C 120 SGCC
1.6*1000*C 80 DX51D+Z 1.6*1250*C 80 DX51D+Z
1.8*1000*C 80 DX51D+Z 1.8*1250*C 80 DX51D+Z
1.9*1000*C 80 DX51D+Z 1.85*1250*C 90 DX51D+Z
1.95*1000*C 180 S350GD 1.95*1250*C 80 DX51D+Z
1.98*1000*C 80 DX51D+Z 1.75*1250*C 80 DX51D+Z
1.95*1000*C 180 S320GD+Z 2.0*1250*C 80 DX51D+Z
1.95*1000*C 180 S280GD+Z 2.0*1250*C 120 SGCC
2.0*1000*C 275 S350+Z 2.5*1250*C 80 DX51D+Z

Specifications︰ Stock Available
Material Dimensions Weight Zinc
SGCC 0.700*1000*C 2.79 Z07
SGCC 0.750*1238*C 4.535 Z275
SGCC 0.330*1200*C 4.24 1
SGCC 0.350*1200*C 6.585 1
SGCC 0.370*1200*C 2.495 1
S280GD 0.360*1250*C 4.485 Z07
S280GD 0.680*1220*C 3.13 Z225
SGHC 2.500*1250*C 22.87 Z07
SGCC 0.370*1200*C 2.3 Z10
SGCC 0.330*1200*C 7.835 Z08
SGCC 0.330*1202*C 8.22 Z08
SGCC 0.370*1200*C 2.95 Z10
SGCC 0.370*1200*C 10.945 Z10
SGCC 0.320*1200*C 21.23 Z08
SGCC 0.330*1200*C 87.66 Z08
SGCC 0.350*1200*C 158.035 Z08
SGCC 0.370*1200*C 12.52 Z08
SGCC 0.750*1170*C 14.06 Z10
SGCC 0.500*1000*C 16.865 Z14
SGCC 0.500*1100*C 4.56 Z14
SGCC 0.370*1200*C 34.455 Z10
SGCC 0.320*1000*C 14.33 Z07
SGCC 0.800*1000*C 2.51 Z07
SGCC 0.900*1220*C 2.36 Z07
SGCC 0.320*1000*C 4.91 Z07
SGCC 0.370*1200*C 5.445 Z10
SGCC 0.700*1000*C 13.82 Z07
SGHC 2.300*1250*C 6.75 Z07
SGCC 0.850*1000*C 157.9 Z07
SGCC 0.850*1000*C 4.65 Z07
SGCC 0.650*1000*C 16.43 Z07
SGCC 0.370*1200*C 5.565 Z10
SGCC 0.370*1200*C 39.195 Z10
SGCC 0.370*1200*C 394.66 Z10
SGCC 0.750*1220*C 6.265 Z07
SGCC 0.850*1000*C 14.28 Z07
SGCC 0.650*1000*C 16.55 Z07
SGCC 0.630*1000*C 75.12 Z07
SGCC 0.650*1250*C 5.25 Z07
SGCC 0.750*1219*C 16.64 Z07
SGCC 0.750*1220*C 15.92 Z07
SGCC 0.370*1200*C 5.7 Z100
S320GD+Z 1.200*1250*C 59.81 Z07
S320GD+Z 1.200*1250*C 13.63 Z07
SGCC 0.350*1000*C 5.89 Z07
SGCC 0.680*1000*C 16.27 Z07
SGCC 0.320*1200*C 106.59 Z08
SGCC 0.320*1200*C 95.255 Z08
SGCC 0.330*1200*C 118.09 Z08
SGCC 0.350*1200*C 81.27 Z08
SGCC 0.350*1200*C 62.095 Z08
SGCC 0.370*1200*C 6.54 Z08
SGCC 0.700*1000*C 3.925 Z07
SGCC 0.750*1000*C 2.55 Z07
SGCC 0.650*1000*C 13 Z07
SGCC 0.850*1000*C 65.42 Z07
SGCC 1.400*1250*C 5.05 Z07
SGHC 2.300*1250*C 15.34 Z07
SGCC 0.550*1219*C 2.16 Z07
SGCC 0.800*1219*C 209.66 Z07
SGCC 0.800*1219*C 2.69 Z07
SGCC 1.200*1000*C 6.13 Z220
SGCC 0.800*1250*C 2.24 Z07
SGCC 1.400*1250*C 14.95 Z07
SGCC 1.250*1000*C 40.22 Z07
S320GD+Z 1.200*1250*C 17.76 Z07
S300GD A 1.200*1250*C 6.89 Z07
SGCC 0.850*1000*C 56.51 Z07
S320GD+Z 1.200*1250*C 69.82 Z07
S300GD A 1.200*1250*C 5.28 Z07
SGCC 1.050*1000*C 23.04 Z07
SGCC 0.700*1219*C 161.05 Z07
SGCC 0.900*1219*C 4.325 Z07
S320GD+Z 1.200*1250*C 24.8 Z07
S300GD A 1.200*1250*C 19.55 Z07
SGCC 0.550*1000*C 168.37 Z07
SGCC 1.500*1250*C 20.66 Z07
SGCC 1.250*1000*C 15.58 Z07
SGHC 1.550*1000*C 15.29 Z07
SGHC 1.550*1000*C 212.89 Z07
SGCC 0.600*1219*C 55.55 Z07
SGCC 0.600*1219*C 2.04 Z07
SGCC 1.250*1000*C 45.6 Z07
SGCC 0.550*1219*C 21.87 Z07
SGCC 0.560*1219*C 9.29 Z120
SGCC 0.330*1200*C 3.7 Z07
SGCC 0.370*1200*C 15.1 Z10
SGHC 1.500*1250*C 7.58 Z07
SGCC 0.500*1250*C 15.03 Z07
SGCC 0.550*1219*C 14.76 Z07
SGCC 0.550*1250*C 193.57 Z07
SGCC 0.600*1219*C 34.52 Z07
SGCC 0.650*1000*C 90.4 Z07
SGCC 0.650*1250*C 364.92 Z07
SGCC 0.550*1000*C 24.01 Z07
SGHC 1.550*1000*C 40.12 Z07
SGHC 2.200*1250*C 13.7 Z200
SGHC 2.200*1250*C 32.62 Z220
SGCC 0.370*1200*C 33.815 Z10
SGCC 0.370*1200*C 8.955 Z10
SGCC 1.450*1000*C 2.16 Z07
SGHC 1.550*1000*C 38.06 Z07
SGHC 1.900*1250*C 7.73 Z07
SGHC 1.900*1250*C 57.92 Z07
SGCC 0.350*1200*C 2.47 1
SGCC 0.380*1250*C 2.41 Z09
SGCC 0.800*1250*C 23.65 Z07
SGCC 0.600*1219*C 45.25 Z07
SGCC 0.650*1000*C 11.27 Z07
SGCC 0.550*1250*C 14.45 Z07
SGCC 0.650*1250*C 15.46 Z07
SGHC 2.000*1250*C 198.8 Z07
SGHC 2.300*1250*C 49.66 Z07
SGHC 2.300*1250*C 15.12 Z07
SGHC 2.500*1250*C 15.63 Z07
SGHC 2.750*1250*C 115.04 Z07
SGHC 3.000*1000*C 297.44 Z07
SGCC 0.800*1219*C 24.38 Z07
SGCC 0.900*1219*C 50.89 Z07
SGCC 0.900*1220*C 3.57 Z07
SGHC 3.000*1250*C 314.97 Z07
SGHC 1.950*1250*C 6.24 Z07
SGCC 0.800*1219*C 14.86 Z07
SGCC 1.000*1219*C 42.4 Z07
SGHC 2.300*1250*C 12.94 Z07
SGCC 0.550*1250*C 55.44 Z07
SGCC 0.550*1250*C 3.47 Z07
SGHC 2.000*1000*C 259.78 Z07
SGHC 2.300*1000*C 6.5 Z07
SGHC 1.900*1000*C 7.04 Z07
SGCC 0.600*1219*C 2.07 Z07
SGHC 1.900*1250*C 83.13 Z07
SGHC 1.950*1250*C 29.68 Z07
SGCC 0.800*1219*C 14.81 Z07
SGHC 2.300*1250*C 306.03 Z07
SGCC 0.550*1250*C 76.91 Z07
SGCC 0.650*1250*C 102.86 Z07
SGHC 2.000*1250*C 313.64 Z07
SGHC 2.000*1250*C 20.27 Z07
SGHC 2.500*1250*C 174.79 Z07
SGHC 1.900*1250*C 85.36 Z07
SGCC 0.550*1250*C 69.76 Z07
SGCC 0.600*1219*C 9.15 Z07
SGCC 0.800*1250*C 28.75 Z07
SGCC 1.000*1219*C 18.92 Z07
SGCC 0.550*1000*C 46.4 Z07
SGCC 1.450*1250*C 15.45 Z07
DX51D Z 0.600*1220*C 4.85 Z10
SGHC 3.000*1250*C 7.79 Z07
SGHC 2.000*1250*C 360.03 Z07
SGHC 2.500*1250*C 286.25 Z07
SGHC 2.500*1250*C 36.71 Z07
SGHC 1.900*1000*C 41.83 Z07
SGHC 2.300*1000*C 83.17 Z07
SGHC 3.000*1250*C 7.8 Z07
SGHC 2.000*1000*C 215.62 Z07
SGCC 0.600*1219*C 3.81 Z07
S320GD+Z 1.000*1000*C 7.37 Z180
SGHC 1.500*1250*C 104.47 Z07
SGHC 1.500*1250*C 24.02 Z07
SGHC 1.900*1250*C 545.2 Z07
SGHC 2.300*1250*C 392.49 Z07
SGHC 2.300*1250*C 66.88 Z07
SGHC 2.300*1250*C 14.49 Z07
SGHC 2.300*1000*C 142.69 Z07
SGHC 1.900*1000*C 106.74 Z07
SGHC 1.800*1250*C 72.43 Z07
SGHC 1.950*1000*C 6.28 Z07
SGHC 1.950*1250*C 95.35 Z07
SGHC 1.900*1000*C 221.43 Z07
SGCC 1.250*1200*C 2.43 Z07
SGHC 1.500*1250*C 23.37 Z07
SGHC 2.000*1000*C 101.75 Z07
SGHC 1.950*1250*C 171.06 Z07
SGHC 2.000*1250*C 121.25 Z07
SGHC 2.300*1250*C 215.23 Z07
SGHC 1.800*1000*C 7.47 Z07
SGHC 1.900*1250*C 292.22 Z07
SGHC 1.900*1000*C 69.14 Z07
SGCC 0.350*1200*C 11.08 Z07
SGCC 0.730*1000*C 3.745 1
SGCC 0.900*1000*C 7.36 Z07
SGCC 1.150*1000*C 55.8 Z07
CS Type B 0.600*1200*C 69.34 Z08
CS Type B 0.700*1200*C 50.66 Z08
CS Type B 0.700*1200*C 6.25 Z08
CS Type B 2.300*1200*C 20.4 Z08
CS Type B 2.300*1200*C 79.11 Z08
CS Type B 1.950*1200*C 12.86 Z08
CS Type B 1.950*1200*C 41.26 Z80
CS Type B 1.950*1200*C 7.13 Z08
CS Type B 1.550*1200*C 12.62 Z80
SGCC 0.600*1219*C 9.36 Z07
SGCC 0.900*1219*C 123.62 Z07
SGCC 0.900*1250*C 16.58 Z07
SGCC 0.950*1000*C 113 Z07
SGCC 1.200*1219*C 151.76 Z07
SGCC 0.700*1250*C 131.54 Z07
SGCC 0.600*1219*C 37.4 Z07
SGCC 0.600*1219*C 2.83 Z07
SGCC 0.800*1250*C 273.08 Z07
SGCC 0.800*1250*C 4.07 Z07
GRADE 40 0.930*1250*C 15.64 G90
SGCC 0.650*1250*C 4.84 Z07
SGCC 0.550*1000*C 97.05 Z07
SGCC 1.200*1000*C 20.11 Z07
SGCC 0.550*1250*C 4.61 1
SGCC 1.050*1250*C 39.57 Z07
SGCC 1.050*1000*C 71.12 Z07
SGCC 0.550*1250*C 9.83 Z07
SGCC 0.750*1000*C 128.35 Z07
SGCC 1.000*1219*C 17.36 Z07
SGCC 1.300*1000*C 4.01 Z07
SGCC 0.350*1000*C 3.89 Z07
SGCC 0.500*1250*C 123.25 Z07
SGCC 0.750*1250*C 61.36 Z07
SGCC 0.950*1000*C 114.63 Z07
SGCC 1.150*1000*C 92.78 Z07
SGCC 0.900*1000*C 94.33 Z07
SGCC 0.950*1250*C 196.56 Z07
SGCC 1.000*1250*C 3.28 Z07
SGCC 0.600*1219*C 46.08 Z07
SGCC 0.750*1000*C 7.48 Z07
SGCC 1.150*1250*C 4.15 Z07
SGCC 1.200*1250*C 3.18 Z07
SGCC 0.400*1000*C 4.49 1
Product Image












Related Products
ASTM A387 CLASS 22  2 1/4  PRESSURE VESSEL STEEL PLATE
ASTM A285,ASTM A387,ASTM A516,ASTM A537,EN 10028-2/3/4 BOILER STEEL PLATE
US $ 685
ASTM A387,ASTM A516,DIN17155,EN 10028-2/3 Pressure Vessel Steel Plate
ASTM A387,ASTM A516,DIN17155,EN 10028-2/3 Pressure Vessel Steel Plate
US $ 750
ASTM A263,ASTM A264,ASTM A265,ASTM B432,ASTM B898  Clad Plate,Bimetallic Plate
ASTM A263,ASTM A264,ASTM A265,ASTM B432,ASTM B898 Clad Plate,Bimetallic Plate
US $ 1200
API 5L B,X42,X46,X52,X56,X60,X70,X80 Steel Plate for the Pipeline Transmmmission
API 5L B,X42,X46,X52,X56,X60,X70,X80 Steel Plate for the Pipeline Transmmmission
US $ 505

Company Profile  |  Products  |  Reference List  |  Association Membership  |  Company News  |  Quality Policy  |  HSE  |  EPCM  |  Catalogue  |  Pipe Specification  |  Coating Specification  |  Pipe Fitting Specs  |  API Specification  |  AS(Australian Standards)  |  DIN(Deutsche Institut für Normun)  |  EN(Europaischen Normen)  |  GOST Specification  |  NF(Norme Francise)  |  Contact Us  |  Sitemap  |  Mobile Version
  English     简体版     繁體版
Powered by DIYTrade.com
HomeContact UsSitemap
