Model No.︰-
Brand Name︰ASTM A193,ASTM A194-Bolts,Nuts,Screws,and studs
Country of Origin︰-
Unit Price︰-
Minimum Order︰-
Share on:

 Total 9 Related Items
Prev12345Next

Product Description



Chemical Compositions (%)
SPECIFICATION/GRADE C SI MN PMAX SMAX NI CR MO VANADIUM
ASTM A193 GR B7 0.37-0.49 0.15-0.35 0.65-1.10 0.035 0.04   0.75-1.20 0.15-0.25
ASTM A193 GR B7M 0.37-0.49 0.15-0.35 0.65-1.10 0.035 0.04 0.75-1.20 0.15-0.25
ASTM A193 GR B16 0.36-0.47 0.15-0.35 0.45-0.70 0.035 0.04 0.80-1.15 0.50-0.65 0.25-0.35
ASTM A193 GR B8 Max 0.08 Max 1.00 Max 2.00 0.045 0.03 8.00-10.5 18.0-20.0
ASTM A193 GR B8M Max 0.08 Max 1.00 Max 2.00 0.045 0.03 10.0-14.0 16.0-18.0 2.0-3.0
ASTM A193 GR B6 Max 0215 Max 1.00 Max 1.00 0.045 0.03     11.5-13.5
ASTM A320 GR L7 0.38-0.48 0.15-0.35 0.75-1.00 0.035 0.04   0.80-1.10 0.15-0.25
ASTM A320 GR L7M 0.38-0.48 0.15-0.35 1.75-1.00 0.035 0.04   0.80-1.10 0.15-0.25
ASTM A320 GR B8 Max 0.08 Max 1.00 Max 2.00 0.045 0.03 8.00-10.5 18.0-20.0
ASTM A320 GR B8M Max 0.08 Max 1.00 Max 2.00 0.045 0.03 10.0-14.0 16.0-18.0 2.0-3.0
ASTM A325 TYPE 1 0.28-0.55   Min 0.60 0.04 0.05   Boron Min 0.0005
ASTM A325 TYPE 2 0.15-0.34 Min 0.70 0.04 0.05
ASTM A354 GR BC 0.30-0.53   0.035 0.04
ASTM A354 GR BD 0.30-0.53 0.035 0.04
ASTM A449 TYPE1 0.28-0.55   Min 0.60 0.04 0.05   Boron Min 0.0005
ASTM A449 TYPE 2 0.15-0.38 Min 0.70 0.04 0.05
ASTM A490 TYPE1 0.30-0.48   0.04 0.04
JIS G4303 SUS310S Max 0.08 Max 1.50 Max 2.00 0.045 0.03 19.0-22.0 24.0-26.0
JIS G4105 SCM 435 0.33-0.38 0.15-0.35 0.60-0.85 0.03 0.03   0.90-1.20 0.15-0.30
JIS G4105 SCM 440 0.38-0.43 0.15-0.35 0.60-0.85 0.03 0.03   0.90-1.20 0.15-0.30
JIS G4107 SNB 5 Min 0.10 Max 1.00 Max 1.00 0.04 0.03   4.00-6.00 0.40-0.65
JIS G4107 SNB 7 0.38-0.48 0.20-0.35 0.75-1.00 0.04 0.04 0.80-1.10 0.15-0.25
JIS G4107 SNB 16 0.36-0.44 0.15-0.35 0.45-0.70 0.04 0.04 0.80-1.15 0.50-0.65
JIS G4051 S45C 0.42-0.48 Max 0.40 0.60-0.90 0.04 0.035
ASTM A194 GR 2H Min 0.40 Max 0.40 Max 1.00 0.04 0.05
ASTM A194 GR 2HM Min 0.40 0.15-0.35 Max 1.00 0.04 0.05
ASTM A194 GR 7M 0.37-0.49 0.15-0.35 0.65-1.10 0.04 0.04 0.75-1.20 0.15-0.25
ASTM A194 GR 4 0.40-0.50 0.15-0.35 0.70-0.90 0.035 0.04   0.20-0.30
ASTM A194 GR 7 0.37-0.49 0.15-035 0.65-1.10 0.04 0.04   0.75-1.20 0.15-0.25
ASTM A194 GR 8 Max 0.06 Max 1.00 Max 2.00 0.045 0.03 8.00-10.5 18.0-20.0
ASTM A194 GR 8M Max 0.08 Max 1.00 Max 2.00 0.045 0.03 10.0-14.0 16.0-18.0 2.00-3.00
ASTM A563 GR A.B.C Max 0.55     0.012 0.15
ASTM A563 GR GR D Max 0.55 Min 0.30 0.04 0.05
ASTM A563 GR GR DH 0.20-0.55 Min 0.60 0.04 0.05

Mechanical Properties
SPECIFICATION GRADE DIAMETER INCH (MM) TESILE STRENGTH MIN YILED STRENGTH MIN E.L % MIN R.A % MIN HAEDNESS TEMPERING TEMP”F (“C) MIN
HB H.B H.C
A193 GR B7 2½ and under 125,000psi 100,000psi 16 50       1,100(593)
Over 2½ to 4 115,000psi 95,000psi 16 50       1,100(593)
A193 GR B7M 2½ and under 105,000psi 80,000psi 18 50 200-235 93-99   1,150(620)
A193 GR B16 2½ and under 125,000psi 105,000psi 18 50 253-319   25-34 1,200(650)
Over 2½ to 4 110,000psi 95,000psi 17 45 353-319   25-34 1,200(650)
A193GRB8.B8M All diameters 75,000psi 30,000psi 30 50 Max 223 Max 96
A193 GR B6 Up to 4 110,000psi 85,000psi 15 50       1,100(593)
A320 GR L7 2½ and under 125,000psi 105,000psi 16 50
A320 GR L7M 2½ and under 100,000psi 80,000psi 18 50 Max 235 Max 99   1,150(620)
A320GRB8.B8M All diameters 75,000psi 30,000psi 35 50 Max 223 Max 96
A325 ½ to 1 120,000psi 92,000psi     248-331   24-35 800(427)
1⅛ to 1½ 105,000psi 81,000psi 14 35 223-293   19-31 800(427)
A354 GR BC ¼ to 2½ 125,000psi 109,000psi 16 50 255-331   26-36 800(427)
Over 1 to 1½ 115,000psi 99,000psi 16 45 235-311   22-33 800(427)
A354 GR BD ¼ to 2½ 150,000psi 130,000psi 14 40 311-363   33-39 800(427)
Over 1 to 1½ 140,000psi 115,000psi 14 40 293-363   31-39 800(427)
A449 ¼ to 1 120,000psi 92,000psi 14 35 255-321   25-34 800(427)
Over 1 to1½ 105,000psi 81,000psi 14 35 223-285   19-30 800(427)
Over 1½ to 3 90,000psi 58,000psi 14 35 183-235     800(427)
A490 ½ to 1½ 150-170ksi 130,000ksi 14 40 311-352   33-38 800(427)
JIS SUS 310S   53 kgf/㎟ 21kgf/㎟ 40 50 Max 187 Max 90
JIS SCM 435   95kgf/㎟ 80kgf/㎟ 15 50 269-331   29-35 (530-630)
JIS SCM 440   100kgf/㎟ 85kgf/㎟ 12 45 285-352   29-39 (530-630)
JIS SNB 5   70kgf/㎟ 56kgf/㎟ 16 50       -595
JIS SNB 7 Up to 63(mm) 88kgf/㎟ 74kgf/㎟ 16 50       -595
Over(63) to (100) 82kgf/㎟ 67kgf/㎟ 16 50       -595
JIS SNB 16 Up to 63(mm) 88kgf/㎟ 74kgf/㎟ 18 50       -650
Over (63) to (100) 77kgf/㎟ 67kgf/㎟ 17 50       -650
JIS S45C   70kgf/㎟ 50kgf/㎟ 17 45 201-269   14.5-27 (550-650)
A194 GR 2           159-352 Min 84   1,000(538)
A194 GR 2H To 1½         248-352   24-38 850(455)
Over 1½         212-352 Min 95 Max 38 850(455)
            159-237   Max 22 1,150
            228-271   20-28 1,100
            159-237   Max 22 1,100
            248-352   24-38 1,100
            126-300 60-105
A563 GR A ¼ to 4         116-302 Min 68 Max 32
A563 GR B ¼ to 1½         121-302 Min 69 Max 32
A563 GR C ¼ to 4         143-352 Min 78 Max 38 800(427)
A563 GR D ¼ to 4         159-352 Min 84 Max 38 800(427)
A563 GR DH ¼ to 4         248-352   24-38 800(427)



ed
