AMS 4922,AMS 4941,AMS 4942,AMS 4943,AMS 4944,AMS 4945 Titanium Tube

AMS 4943, 4944, 4945, 4946, AS 5620  3AL-2.5V/ ASTM A338 Gr.9 Titanium Seamless Tube
  • AMS 4943, 4944, 4945, 4946, AS 5620  3AL-2.5V/ ASTM A338 Gr.9 Titanium Seamless Tube
  • AMS 4945 Ti-3Al-2.5V Titanium Tube Gr9 R56320 Titanium Seamless Tube
  • ASTM B338 Gr.2 Titanium Alloy Tubes
  • AMS 4941, AMS 4942, AMS 4902, ASTM B338, ASME SB 338, DMS-1872, ASTM B-861, BMS 7-21, CMMP026 CP Ti 40 Titanium Tube
  • AMS 4945 Ti-3Al-2.5V U-Bent Titanium Tube Gr9 R56320 Titanium Seamless Tube
  • ASTM B337 Gr1 Titanium Tube
  • ASTM B338 Gr.2 Seamless Titanium Tube
  • ASTM B861 Gr.2 Seamless Titanium Tube
  • ASTM B861 Gr.12 Titanium Heat Exchanger Tube
  • ASTM B862 GR.2 WELDED TITANIUM TUBE
  • Anodizing Titanium Alloy Tubes
Model No.︰-
Brand Name︰ASTM A338/ASME SA338 TITANIUM TUBE
Country of Origin︰-
Unit Price︰US $ 2.3 / kg
Minimum Order︰10 kg
Share on:

 Total 5 Related Items
Prev12345Next

Product Description



Reference Specifications:

ASTM B338/ASME SB338 Seamless and Welded Titanium &Titanium Alloy Tubes for Condensers & Heat Exchangers

ASTM B363/ASME SB363 Seamless and Welded Unalloyed Titanium & Titanium Alloy Welding Fittings

ASTM B861/ASME SB861 Titanium and Titanium Alloy Seamless Pipe

ASTM B862/ASME SB862 Titanium and Titanium Alloy Welded Pipe

AMS 4922  Seamless Hydraulic Tubing - Cold Worked and Precipitation Heat Treated---Titanium Alloy - 15V-3.0CR-3.0AL-3.0SN

AMS 4941  Tubing, Welded, Annealed, 40,000 psi (275 MPa) Yield Strength

AMS 4942  Tubing, Seamless, Annealed, 40,000 psi (275 MPa) Yield Strength

AMS 4943  Hydraulic, Seamless Tubing 3.0AL-2.5V Annealed

AMS 4944  Seamless, Hydraulic Tubing 3.0AL-2.5V Cold Worked, Stress Relieved

AMS 4945  Tubing, Seamless, Hydraulic, 3AL-2.5V, Texture Controlled, 105 ksi (724 Mpa)Yield Strength Cold Worked, Stress Relieved

DIN 17861 Seamless Circular Titanium And Titanium Alloy Tubes

DIN 17866 Welded Circular Titanium And Titanium Alloy Tubes



Grades Available

  • Gr1 R50250titanium tube, CP titanium, low oxygen
  • Gr2 R50400titanium tubing, CP titanium, standard oxygen
  • Gr7 R52400titanium pipe, Ti-Pd, standard oxygen
  • Gr9 R56320titanium piping, Ti-3Al-2.5V
  • Gr11 R52250titanium alloy tube, Ti-Pd, low oxygen
  • Gr12 R53400titanium alloy tube, Ti-Mo-Ni
  • Gr16 R52402titanium alloy pipe, Ti-Pd, standard oxygen
  • Gr17 R52252titanium alloy pipe, Ti-Pd, low oxygen



Features of Titanium Grades:

  • Titanium Grade 1
  • This is a non-alloyed, low strength titanium product containing low oxygen with high formability. This grade is used in airframes, heat exchangers and desalination units.
  • Titanium Grade 2
  • This is a non-alloyed, medium strength titanium product. This grade is used in airframes, aircraft engines, and marine equipment. This grade features good weldability and corrosion resistance.
  • Titanium Grade 3
  • This is a non-alloyed, high strength titanium product providing excellent corrosion resistance and good weldability. This grade is primarily used in airframes and aircraft engine parts.
  • Titanium Grade 4
  • This is the highest strength pure non-alloyed titanium product. This grade is used exclusively for aircraft components, marine equipment, surgical implants, and hydraulic tubing. It contains good formability and it is corrosion resistant.
  • Titanium Grade 5 (6Al – 4V)
  • This is an alloyed products containing 6% aluminum and 4% vanadium.
  • Titanium Grade 7
  • This is a non-alloyed medium strength product containing palladium in the range of 0.12% to 0.25%. It has superior corrosion resistance. This grade is mainly used for industrial applications.
  • Titanium Grade 9 (3Al – 2.5V)
  • This is an alloyed titanium product containing 3% aluminum and 2.5% vanadium.
  • 6AL - 2Sn - 4Zr - 2Mo (6-2-4-2)
  • This is an alloyed product containing 6% aluminum, 2% tin, 4% zirconium, and 2% molybdenum.
  • 6AL - 6V - 2Sn (6-6-2)
  • This is an alloyed product containing 6% aluminum, 6% vanadium, and 2% tin.
  • 5AL - 2.5Sn (5-2.5)
  • This is an alloyed product containing 5% aluminum and 2.5% tin.
  • 8AL-1V-1Mo (8-1-1)
  • This is an alloyed product containing 8% aluminum, 1% vanadium, and 1% molybdenum.



Applications:

Oil and gas industry

Chloride environments such as seawater handling and process systems and hydraulic and process fluid tubes in umbilicals.

Seawater cooling

Tubing for heat exchangers and coolers on oil platforms, in refineries, chemical industries, process industries and other industries using seawater or chlorinated seawater as coolant.

Refineries and petrochemical plants

Tubes and pipes where the process environment contains a high amount of chlorides or sulfides.

Geothermal wells

Heat exchangers in geothermal exploitation units, systems exposed to geothermal or high-salinity brines, tubing and casing for production.

Pulp and paper industry

Tubing for chloride containing bleaching environments.

Desalination plants

Tube and pipe for seawater transport, heat exchanger tubing, and pressure vessels for reverse osmosis units.

Mechanical components requiring high strength

Propeller shafts and other products subjected to high mechanical load in seawater and other chloride-containing environments. Excellent mechanical and corrosion resistance properties make titanium tubing and pipe an economical choice for many other applications by reducing the product life cycle costs of equipment.



Product Image

AMS 4943, 4944, 4945, 4946, AS 5620  3AL-2.5V/ ASTM A338 Gr.9 Titanium Seamless Tube
AMS 4943, 4944, 4945, 4946, AS 5620 3AL-2.5V/ ASTM A338 Gr.9 Titanium Seamless Tube

AMS 4945 Ti-3Al-2.5V Titanium Tube Gr9 R56320 Titanium Seamless Tube
AMS 4945 Ti-3Al-2.5V Titanium Tube Gr9 R56320 Titanium Seamless Tube

ASTM B338 Gr.2 Titanium Alloy Tubes
ASTM B338 Gr.2 Titanium Alloy Tubes

AMS 4941, AMS 4942, AMS 4902, ASTM B338, ASME SB 338, DMS-1872, ASTM B-861, BMS 7-21, CMMP026 CP Ti 40 Titanium Tube
AMS 4941, AMS 4942, AMS 4902, ASTM B338, ASME SB 338, DMS-1872, ASTM B-861, BMS 7-21, CMMP026 CP Ti 40 Titanium Tube

AMS 4945 Ti-3Al-2.5V U-Bent Titanium Tube Gr9 R56320 Titanium Seamless Tube
AMS 4945 Ti-3Al-2.5V U-Bent Titanium Tube Gr9 R56320 Titanium Seamless Tube

ASTM B337 Gr1 Titanium Tube
ASTM B337 Gr1 Titanium Tube

ASTM B338 Gr.2 Seamless Titanium Tube
ASTM B338 Gr.2 Seamless Titanium Tube

ASTM B861 Gr.2 Seamless Titanium Tube
ASTM B861 Gr.2 Seamless Titanium Tube

ASTM B861 Gr.12 Titanium Heat Exchanger Tube
ASTM B861 Gr.12 Titanium Heat Exchanger Tube

ASTM B862 GR.2 WELDED TITANIUM TUBE
ASTM B862 GR.2 WELDED TITANIUM TUBE

Anodizing Titanium Alloy Tubes
Anodizing Titanium Alloy Tubes
