ASTM B337,ASTM B338,ASTM B861,ASTM B862,DIN 17861,DIN 17866 Titanium Tube

ASTM B337 Gr 1 Titanium Tube
  • ASTM B337 Gr 1 Titanium Tube
  • ASTM B338 GR2 Titanium Tube
  • ASTM B338 GR. 9 ANNEALED TATANIUM TUBE
  • ASTM B861 GR.12 OD16mmxWT0.5x1600mm Titanium Tube
  • ASTM B862 GR.2 WELDED TITANIUM TUBE
  • ASTM B862 GR5 Heat Resistant Titanium Alloy Tube
  • DIN 17861,DIN 17866 3.7025,3.7035,3.7055,3.7235,3.7195,3.7105 Seamless circular titanium and titanium alloy tubes
  • ASTM B337,ASTM B338,ASTM B861,ASTM B862,DIN 17861,DIN 17866 Titanium and Titanium Alloy Tubes
  • PVD Coated Titanium Pipe
  • Tubesheet Titanium Clad Steel Shell for Heat Exchanger-Pressure Vessel
  • ASTM-B338 Gr. 2 Titanium Coil Tubing For Chemical
  • ASTM B337,ASTM B338,ASTM B861,ASTM B862,DIN 17861,DIN 17866 Titanium Tube
Model No.︰-
Brand Name︰ASTM A338/ASME SA338 TITANIUM TUBE
Country of Origin︰-
Unit Price︰US $ 2.3 / kg
Minimum Order︰10 kg
Share on:

 Total 5 Related Items
12345Next

Product Description



Reference Specifications:

ASTM B338  Seamless and Welded Titanium &Titanium Alloy Tubes for Condensers & Heat Exchangers
ASTM B363 Seamless and Welded Unalloyed Titanium & Titanium Alloy Welding Fittings
ASTM B861 Titanium and Titanium Alloy Seamless Pipe
ASTM B862 Titanium and Titanium Alloy Welded Pipe

AMS 4941 Tubing, Welded, Annealed, 40,000 psi (275 MPa) Yield Strength
AMS 4942 Tubing, Seamless, Annealed, 40,000 psi (275 MPa) Yield Strength
AMS 4943 Hydraulic, Seamless Tubing 3.0AL-2.5V Annealed
AMS 4944 Seamless, Hydraulic Tubing 3.0AL-2.5V Cold Worked, Stress Relieved
AMS 4945 Tubing, Seamless, Hydraulic, 3AL-2.5V, Texture Controlled, 105 ksi (724 Mpa)Yield Strength Cold Worked, Stress Relieved

DIN 17861              Seamless Circular Titanium And Titanium Alloy Tubes
DIN 17866              Welded Circular Titanium And Titanium Alloy Tubes





Features of Titanium Grades:

  • Titanium Grade 1
  • This is a non-alloyed, low strength titanium product containing low oxygen with high formability. This grade is used in airframes, heat exchangers and desalination units.
  • Titanium Grade 2
  • This is a non-alloyed, medium strength titanium product. This grade is used in airframes, aircraft engines, and marine equipment. This grade features good weldability and corrosion resistance.
  • Titanium Grade 3
  • This is a non-alloyed, high strength titanium product providing excellent corrosion resistance and good weldability. This grade is primarily used in airframes and aircraft engine parts.
  • Titanium Grade 4
  • This is the highest strength pure non-alloyed titanium product. This grade is used exclusively for aircraft components, marine equipment, surgical implants, and hydraulic tubing. It contains good formability and it is corrosion resistant.
  • Titanium Grade 5 (6Al – 4V)
  • This is an alloyed products containing 6% aluminum and 4% vanadium.
  • Titanium Grade 7
  • This is a non-alloyed medium strength product containing palladium in the range of 0.12% to 0.25%. It has superior corrosion resistance. This grade is mainly used for industrial applications.
  • Titanium Grade 9 (3Al – 2.5V)
  • This is an alloyed titanium product containing 3% aluminum and 2.5% vanadium.
  • 6AL - 2Sn - 4Zr - 2Mo (6-2-4-2)
  • This is an alloyed product containing 6% aluminum, 2% tin, 4% zirconium, and 2% molybdenum.
  • 6AL - 6V - 2Sn (6-6-2)
  • This is an alloyed product containing 6% aluminum, 6% vanadium, and 2% tin.
  • 5AL - 2.5Sn (5-2.5)
  • This is an alloyed product containing 5% aluminum and 2.5% tin.
  • 8AL-1V-1Mo (8-1-1)
  • This is an alloyed product containing 8% aluminum, 1% vanadium, and 1% molybdenum.
