ASTM A270,DIN 11850,EN 10357 Hygienic Tubes,Sanitary Tubes

1.4301 Sanitary Metric Stainless Steel Tubing DIN 11850 104 X 2.0MM With OD Polished
  • 1.4301 Sanitary Metric Stainless Steel Tubing DIN 11850 104 X 2.0MM With OD Polished
  • ASTM A270 316L STAINLESS STEEL SANITARY TUBE
  • ASTM A270,DIN 11850,EN 10357 Hygienic Tubes,Sanitary Tubes
  • ASME SA213M 304/304L Stainless Steel Heat Exchanger Pipe
  • DIN 11850/DIN 11851 Sanitary Stainless Steel Pipe
  • ASTM A269 TP316L Polishing Stainless Steel Tube Tubing
  • Mechanical Polishing
  • ASTM A270,DIN 11850,EN 10357 Hygienic Tubes,Sanitary Tubes
Model No.︰-
Brand Name︰-
Country of Origin︰-
Unit Price︰US $ 11.5 / KG
Minimum Order︰100 KG
Share on:

 Total 28 Related Items
Prev34567Next

Product Description

Sanitary Tubing
Sanitary tubing is a kind of tubing having a special surface, commonly polishing process is carried out for high performance tubing, sanitary tubing is for use in the bakery, beverage, dairy, food, biotechnology or pharmaceutical Industries.
Tubing should conform to ASTM A270 and 3A sanitary standards requirement, in both welded and seamless types.
Stainless steel is a ideal material for sanitary tubing, it has good corrosion resistance with high strength, that is basic properties of stainless steel, tubing is easy to clean outside and inside, removing residues, and stainless steel material is no harmful to human healthy.

Polishing Tubing
To achieve smooth surface, tubing always is needed to make polishing process, mechanical polishing is most used method to smooth tubing surface.
Roughness is measured using Ra value, common Ra value is less than 0.8 μm for outside and inside surface, after polishing, roughness value reaches 0.2 μm.
Polishing grit contains 180, 320, 400, mirror finish.
Sanitary Tubing Quality
Welded tubes are main types for sanitary purpose, we use TIG automatic welding method to manufacture tubing, then annealed, minimum temperature is 1040 degree C, rapidly cooled to achieve the maximum cold finish effect
Each tubing should be conducted eddy current testing to ensure high quality tubing, other tests conform to ASTM A270 specification.
Stainless steel sanitary tubing is to joint with other components, fittings, tees, valves.

ASTM A 270 Specification for Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing

DIN 11850 Tubes for the food, chemical and pharmaceutical industry - Stainless steel tubes - Dimensions,materials
AS 1528.1  Tubes (stainless steel) and tube fittings for the food industry.
JIS G 3447 Stainless Steel Sanitary Pipestry Part 1-Tube



Product Image

1.4301 Sanitary Metric Stainless Steel Tubing DIN 11850 104 X 2.0MM With OD Polished
1.4301 Sanitary Metric Stainless Steel Tubing DIN 11850 104 X 2.0MM With OD Polished

ASTM A270 316L STAINLESS STEEL SANITARY TUBE
ASTM A270 316L STAINLESS STEEL SANITARY TUBE


ASME SA213M 304/304L Stainless Steel Heat Exchanger Pipe
ASME SA213M 304/304L Stainless Steel Heat Exchanger Pipe

DIN 11850/DIN 11851 Sanitary Stainless Steel Pipe
DIN 11850/DIN 11851 Sanitary Stainless Steel Pipe

ASTM A269 TP316L Polishing Stainless Steel Tube Tubing
ASTM A269 TP316L Polishing Stainless Steel Tube Tubing

Mechanical Polishing
Mechanical Polishing
