API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles

API 5L X65 Steel Tubular Pile
  • API 5L X65 Steel Tubular Pile
  •  EN 10219 S355J2H LSAW STEEL PIPE PILES
  • ASTM A252 GR.2 ERW PIPE PILES
  • AS 1163 C350L0 ERW PIPE PILES
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
  • API 2B,API 5L,ASTM A252, AS 1163, EN 10219-1, EN 10225-1 Steel Tubular Piles
Model No.︰-
Brand Name︰ASTM A252 Steel Tubular Pile/ASTM A200 Water Pipe
Country of Origin︰-
Unit Price︰US $ 1180 / MT
Minimum Order︰50 MT
Share on:

 Total 20 Related Items
12345Next

Product Description

Tubular piles are tubular pipes used for piling purposes,which are also called steel piles,piping tubes,or tubular piling. Tubular piles are normally large diameter piles because bigger bending moment are required in lots of cases.

Our Advantages

Ø With our pipe pile mill strategically located near the port and our strong steel pile production ability, No limit on tubular pile dimensions, This is especially important for deep foundations,quay wall, cofferdam,Jetty construction. The biggest tubular pipes we have produced, length up to 100m,diameter up to 3m.Any steel grade,X70 or S460 or A690,as long as you name it, we will produce for your steel piles.

Ø Our steel piling factory will produce the required sheet piles sizes, and corner sections as well. So that we will ship with tubular piles in one shipment, you just need to install them at jobsites.

 Ø Further fabrications, like piling shoes, lifting ligs, weld beads, beveled ends, corner sections, paintings...etc we can all do in our workshops.SGS or BV Inspection report is normally supplied.

Paintings

Our inhouse painting facilities allows for any kind of anti-corrosion protection: Painting, Petrolatum Tapes, Galvanizing.

Tubular Pile Application

Pipe piles are produced from different steel grade for wide applications, for example, foundation pipes, king pile, monopile, bearing pile, pipe pile wall, slope stabilization, pipelines, deep foundation, deep-water dock pile and struts etc.

Complex Fabrications

  Sheet pile interlocks

  Factory made L& T clutches

  Small pipe connectors

  Sheet pile welded on pipes

  Pipe driving shoes

  For floating fenders

  For pipe-pipe combiwall

  Interior and exterior weld beading

  Lifting holes

  Shear rings

  End covers

  Additional modifications (brackets, tongue plates etc) also available

ACCESSORIES | Pipe Piling

Chill Rings

A chill ring includes a cylindrical non-consumable base metal ring having an outside diameter sized to fit adequately inside the diameter of the pipe end to be welded.

Conical Points

Conical points are used to push the earth aside and maintain grinding. On rough surfaces, the point distributes the load around the entire pipe, rather than focusing the shock on only a section.

Cutting Shoes

A open-end cutting shoe is an exceptionally tough, heat-treated cast steel shoe with a ledge to ease driving. Use of a cutting shoe protects the pipe end and makes it possible to use a thinner pipe.

Pipe Caps

Pipe caps are available in all standard sizes ranging from 8 5/8" to 72".

Pipe Splicers

Pipe piling splicers are available in all pipe sizes. Pipe splicers help ease alignment of pipe and drive it with no welding required.



Reference Specification:

API 2B Specification for the Fabrication of Structural Steel Pipe- ASTM 572 Gr.50, EH36TM, DH36, DH36TMZ

API 5L PSL1/PSL 2 Line Pipe: Gr. B X42, X46, X52, X56, X60, X65, X70, X80/BM.X42M,X46M,X52M,X60M,X65M,X70,X80M

AS 1163 Structural Steel Hollow Sections-C250,C250L0,C350,C350L0,C450,C450L0

AS 1579 Arc-welded steel pipes and fittings for the piling purpose

ASTM A252 FOUNDATION PILES for soil consolidation, marine wharfs-Grade 1,2,3ASTM A500 Standard Specification for Cold-Formed Welded and Seamless Carbon Steel Structural Tubing in Rounds and Shapes

BS 7191 All Specification for Weldable Structure Steels for Fixed Offshore Structures

CSA Z245.1 Steel Pipe- Category I, II, III-241,290,359,386,414,448,483,550,620,690,825

JIS A5525 Steel Pipe Pile-SPS290,SPS400,SPS490,SP500,SPS500

KS F4602 Steel Pipes Piles

KS F4605 Steel Pipe Sheet Pile

Coating Specifications

Fusion Bonded Epoxy – Fusion Bond Epoxy is a powder epoxy thermosetting coating applied for anticorrosion protection to steel pipelines. The pipe is first blast cleaned and heated. Then epoxy powder is spray applied by electrostatic guns to melt and form a uniform layer that hardens within a minute from application. Utilizing industry accepted materials supplied by manufacturers such as 3M, DuPont, and Valspar, the facility can apply FBE in a wide range of thickness to cost effectively meet any project specifications.

Fusion Bonded Epoxy with Abrasion Resistance Overcoating (FBE/ARO) – Utilizing two completely separate powder systems, the facility can produce FBE with an ARO at unprecedented processing speeds using industry accepted materials such as 3M 6352, DuPont 7-2610, and Lilly 2040.

Fusion Bonded Epoxy with High Temperature Resistant Overcoating – Utilizing two completely separate powder systems, the facility can produce FBE with a high operating temperature resistant overcoating such as DuPont’s Nap-Gard Gold and 3M’s 6258.

Fusion Bonded Epoxy with Zap-Wrap Overcoating – The facility is capable of processing line pipe with connections and of applying the Zap-Wrap abrasion resistance overcoating to the ends of each pipe.

ASTM A950: Standard Specification for Fusion-Bonded Epoxy-Coated Structural Steel H-Piles and Sheet Piling.

ASTM A972: Standard Specification for Fusion-Bonded Epoxy-Coated Pipe Piles.

CSA-Z245.20 Standard for External Fusion Bond Epoxy Coating for Steel Pipe

AS 3862 Standard Specification for External Fusion-Bonded Epoxy Coating for Steel Pipes

AWWA C213 Standard for Fusion Bonded Epoxy Coating for the Interior and Exterior of Steel Water Pipelines.

EN 10289 Steel Tubes and Fittings for Onshore and Offshore Pipelines-External Liquid Epoxy and Epoxy-Modified Coating

ISO 21809-2 Petroleum and natural gas industries-External coatings for buried or submerged pipelines used in pipeline transportation systems-Part 2: Fusion-bonded epoxy coatings

ISO 12944 Paints & Varnishes – Corrosion Protection of Steel Structures by protective paint system (parts 1 – 8)

ISO 20340 Paints and varnishes – Performance requirements for protective paint systems for offshore and related structures

ISO 15741: Paints and Varnishes - Friction-Reduction Coatings for the Interior of On-and Offshore Steel Pipelines for Non-Corrosive Gas.

NACE RP0394-2002: Application, Performance, and Quality Control of Plant-Applied, Fusion-Bonded Epoxy External Pipe Coating.



Coating Material Applied

3M: SK 134, SK6233, SK6352 Toughkote, SK 314, SK 323, SK 206N, SK 226N, SK 6251 DualKote SK-6171, SK 206P, SK226P,

3M Internal Coatings: Coupon EP2306HP

DuPont: 7-2500, 7-2501, 7-2502, 7-2508, 7-2514, 7-2803, 7-2504 Nap Gard Gold 7-2504, Nap Rock: 7-2610, 7-2617 FBE Powders

DuPont: Repair Kits; 7-1631, 7-1677, 7-1862, 7-1851

DuPont Internal Coatings: 7-0008, 7-0010, 7-0014, 7-0009SGR, 7-0009LGR, 7-2530, 7-2534, 7-2509

Akzo Nobel: Interzone 485,Interzone 505,Interzone 954,Internline 876 Seal Coat

Hampel: 85448,97840

Denso: 7200, 7900 High Service Temperature Coatings

Internal Liquid Epoxy: Powercrete Superflow
