ASTM A671,ASTM A672,ASTM A691,EN 10217-5/6 EFW (Electric Fusion Welded) Pipe

ASTM A672 CC55 CL23 EFW PIPE
  • ASTM A672 CC55 CL23 EFW PIPE
  • ASTM A691 1 1/4CR C22 EFW PIPE
  • ASTM A672 CC70 CL22 457.2x39.67mm SAWL PIPE
  • ASTM A691 5Cr Cl42 Φ914x12.7mm EFW Steel Pipe  For Petrochemical Industry
  • ASTM A671,ASTM A672,ASTM A691,EN 10217-5/6  EFW (Electric Fusion Welded) Pipe
  • ASTM A671,ASTM A672,ASTM A691,EN 10217-5/6  EFW (Electric Fusion Welded) Pipe
  • ASTM A671,ASTM A672,ASTM A691,EN 10217-5/6  EFW (Electric Fusion Welded) Pipe
  • ASTM A387
Model No.︰EFW PIPE,A671
Brand Name︰ASTM A671,ASTM A672,ASTM A691,EFW PIPE
Country of Origin︰-
Unit Price︰US $ 1720 / MT
Minimum Order︰50 MT
Share on:

 Total 20 Related Items
Prev34567Next

Product Description

EFW steel pipe (Electric Fusion Welding steel pipe) refers to an electron beam welding, the use of high-speed movement of the electron beam directed impact kinetic energy is converted to heat the workpiece so that the workpiece leaving the melt, the formation of the weld. EFW steel pipe is formed by rolling plate and welding the seam. The weld flash can be removed from the outside or inside surfaces using a scarfing blade. The weld zone can also be heat treated to make the seam less visible. Welded pipe often has tighter dimensional tolerances than seamless, and can be cheaper if manufactured in the same quantities. It is mainly used for welding dissimilar steel welding sheet or which high power density, metal weldment can rapidly heated to high temperatures, which can melt any refractory metals and alloys. Deep penetration welding fast, heat-affected zone is extremely small, so small performance impact on the joints, the joint almost no distortion. But it has a requirement on a special welding room because welding using X-rays.





{"2":"","3":"","4":"SIZE RANGE OF PRESS AND ROLL BENDED EFW PIPE"}



 {}

Product Image

ASTM A672 CC55 CL23 EFW PIPE
ASTM A672 CC55 CL23 EFW PIPE

ASTM A691 1 1/4CR C22 EFW PIPE
ASTM A691 1 1/4CR C22 EFW PIPE

ASTM A672 CC70 CL22 457.2x39.67mm SAWL PIPE
ASTM A672 CC70 CL22 457.2x39.67mm SAWL PIPE

ASTM A691 5Cr Cl42 Φ914x12.7mm EFW Steel Pipe  For Petrochemical Industry
ASTM A691 5Cr Cl42 Φ914x12.7mm EFW Steel Pipe For Petrochemical Industry




ASTM A387
ASTM A387
