DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube

DIN 2391C/DIN 2445/EN 10305-4 St.37.4 Seamless Cold Drawn Precision Steel Tube
  • DIN 2391C/DIN 2445/EN 10305-4 St.37.4 Seamless Cold Drawn Precision Steel Tube
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
  • 10305-3 Precision Steel Tube
  • DIN 2391 ST35 BK Thick Wall High – Precision Steel Tube, Round Cold Rolled/Drawn Pipe
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
  • DIN 2391 St37.4/St52.4,EN 10305-1/4 E235/E355,BS 6323-4,JIS G3445 Precision Tube
Model No.︰-
Brand Name︰DIN 2391,EN10305-4,AS1450 PRECISION SEAMLESS TUBE
Country of Origin︰-
Unit Price︰US $ 1500 / MT
Minimum Order︰20 MT
Share on:

 Total 15 Related Items
Prev910111213Next

Product Description

Delivery Condition And Precision Tubes Surface

Precision tubes are supplied in condition that is presented in the table below. It is marking for thermal processing according to EN 10305-1.
+C Cold drawn / hard.
After the last cold forming no heat treatment.
+LC Cold drawn / soft. After the last heat treatment follows the cold drawing there is a light finishing pass.
+SR Cold drawn and stress relieved annealed. After the final cold drawing process the tubes are stress relieved annealed in a controlled atmosphere.
+A Annealed. After the last cold drawing process the tubes are annealed in a controlled atmosphere.
+N Normalized.
After the last cold drawing process the tubes are annealed in a controlled atmosphere.
Product Image

DIN 2391C/DIN 2445/EN 10305-4 St.37.4 Seamless Cold Drawn Precision Steel Tube
DIN 2391C/DIN 2445/EN 10305-4 St.37.4 Seamless Cold Drawn Precision Steel Tube




10305-3 Precision Steel Tube
10305-3 Precision Steel Tube

DIN 2391 ST35 BK Thick Wall High – Precision Steel Tube, Round Cold Rolled/Drawn Pipe
DIN 2391 ST35 BK Thick Wall High – Precision Steel Tube, Round Cold Rolled/Drawn Pipe
