Model No.︰PC Strand Wire
Brand Name︰PC Strand Wire , PC Steel Wire , PC Wire
Country of Origin︰-
Unit Price︰-
Minimum Order︰-
Share on:

 Total 20 Related Items
Prev1011121314Next

Product Description

 Prestressed PC Steel Wire for Concrete

Prestressed PC steel wire application: Prestressed concrete strand is used of prestressed concrete structure reinforced, such as large-span bridges on railway and highway, overhead crane beam, rock-soil anchoring project, multi-storey industrial buildings, stadiums, mines and etc. PE coated steel strand for prestressed concrete is suitable for large-span and large bays cast-in-place concrete floor, large load of precast beams and other special structure.

{}



{}



{}





Reference Standards:

ASTM A416/A416M Steel Strand, Uncoated Seven-Wire for Prestressed Concrete
ASTM A421/A416M Stress-Relieved Steel Wire for Prestressed Concrete
ASTM A475/A475M  Class A Zinc-Coated Steel Wire Strand
ASTM A882/A882M  Filled Epoxy-Coated Seven-Wire Prestressing Steel Strand
ASTM A884/A884M Epoxy-Coated Steel Wire and Welded Wire Reinforcement
ASTM A1064/A1064M Carbon-Steel Wire and Welded Wire Reinforcement, Plain and Deformed, for Concrete
ASTM A1114/A1114M Low-Relaxation, Seven-Wire, Grade 240, Stainless Steel Strand for Prestressed Concrete
ASTM D6386 Zinc (Hot Dip Galvanized) Coated Iron & Steel Product & Hardware Surfaces for Painting
BS 5896 High Tensile Steel Wire and Strand for the Prestressing of Concrete
EN 10138-3 Prestressing steels - Part 3: Strand
JIS G 3536 Steel Wires And Strands For Prestressed Concrete

Product Image

ASTM A416,BS 5896,EN10138,AS 4672,JIS G3536 PC Strand
ASTM A416,BS 5896,EN10138,AS 4672,JIS G3536 PC Strand

ASTM A1114 Low-Relaxation, Seven-Wire, Grade 240 [1655], Stainless Steel Strand for Prestressed Concrete
ASTM A1114 Low-Relaxation, Seven-Wire, Grade 240 [1655], Stainless Steel Strand for Prestressed Concrete

ASTM A475/BS 183  Galvanized steel strand for Guy wire Stay Wire
ASTM A475/BS 183 Galvanized steel strand for Guy wire Stay Wire

ASTM A416 Grade 270 1860 MPA 15.24mm PC Steel Wire/Stiffness Stranded Steel Cable
ASTM A416 Grade 270 1860 MPA 15.24mm PC Steel Wire/Stiffness Stranded Steel Cable

ASTM A416/BS 5896 PC Strand, Prestressed Concrete Steel Strand
ASTM A416/BS 5896 PC Strand, Prestressed Concrete Steel Strand

Galvanized Steel Wire Strand Steel Messenger Cable ASTM A 475 Class A EHS
Galvanized Steel Wire Strand Steel Messenger Cable ASTM A 475 Class A EHS

Galvanized Steel Wire Strand For Stay Wire , High Strength-Middle Strength And Low Strength 2
Galvanized Steel Wire Strand For Stay Wire , High Strength-Middle Strength And Low Strength 2

Wire Strand Packaging
Wire Strand Packaging
