ASTM A213,ASTM A269,ASTM A312,DIN 17458,EN10216-5 SEAMLESS STAINLESS PIPE
|
|
| Model No.︰ | - |
| Brand Name︰ | ASTM A213,ASTM A312,ASTM A789,EN10216-5 |
| Country of Origin︰ | - |
| Unit Price︰ | US $ 8.5 / Kg |
| Minimum Order︰ | 1000 Kg |
|
|
|
|
|
|
|
|
ASTM/ASME Standards
ASTM A 213/A 213M ASME SA213/SA213M Specification for Seamless Ferric and Austenitic Alloy-Steel Boiler, Su[perheater, and Heat-Exchanger Tubes
ASTM A 249/A 249M Specification for Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser tubes
ASTM A268/A268M, ASME SA268/SA268M Specification Seamless and welded ferritic and martensitic stainless steel tubing for general service
ASTM A269/A269M, ASME SA269/SA269M Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
ASTM A 270 Specification for Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing
ASTM A312/A312M, ASME SA312/SA312M Specification for Seamless and Welded Austenitic Stainless Steel Pipes
ASTM A 358/A 358M Specification for Electric-Fusion-Welded Austenitic Chromium-Nickel Alloy Steel Pipe for High-Temperature Service
ASTM A376/A376M, ASME SA376/SA376M Seamless austenitic steel pipes for high-temperature central-station service
ASTM A409/SA409 Welded Large Diameter Austenitic Steel Pipe for Corrosive or High Temperature Service
ASTM A 450/A 450M Specificaion for General Requirements for Carbon, Ferritic Alloy, and Austenitic Alloy Steel Tubes
ASTM A 511 Specification for Seamless Stainless Steel Mechanical Tubing
ASTM A 530/ A 530M Specification for General Requirements for Specialized Carbon and Alloy Steel Pipe
ASTM A 554 Specification for Welded Stainless Steel Mechanical Tubing
ASTM A 688 / SA 688 For Welded feed water heater ‘U’ Tubes
ASTM A731 / A731M Seamless and Welded Ferritic and Martensitic Stainless Steel Pipe
ASTM A 778 Specification for Welded, Unannealed Austenitic Stainless Steel Tubular Products
ASTM A789/A789M, ASME SA789/SA789M Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service
ASTM A790/A790M, ASME SA790/SA790M Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe
ASTM A791 / A791M Welded Un-annealed Ferritic Stainless Steel Tubing
ASTM A 999/A 999M Specification for General Requirements for alloy and Stainles Steel Pipe
BS-Standards
BS 3059 Steel boiler and super heater tubes
BS 3605 Austenitic stainless steel pipes and tubes for pressure purposes
BS 3606 Steel tubes for heat exchangers
NF-Standards
NF A 49-117 Seamless ferritic and austenitic stainless steel tubes for general service
NF A 49-217 Seamless ferritic, austenitic, and ferritic-austenitic stainless steel tubes for heat exchangers
NF A 49-317 Seamless plain-end austenitic stainless steel mechanical tubing
German-Standards
DIN 17456 Seamless circular austenitic stainless steel tubes for general service
DIN 17457 Welded circular austenitic stainless steel tubes subject to special requirements
DIN 17458 Seamless circular austenitic stainless steel tubes subject to special requirements
DIN 17459 Seamless circular high-temperature austenitic stainless steel tubes
DIN 28180-85 Seamless steel tubes for tubular heat exchangers
DIN EN ISO 1127 Seamless stainless steel tubes (Dimensions and weights)
EN Standards
EN 10216-5 Welded Stainless Steel Tube
EN 10216-7 Seamless Stainless Steel Tube
Australian Standards
AS 1528 Tubes (Stainless Steel) and Tube Fittings for the Food Industry.
JIS-Standards
JIS G 3447 Stainless Steel Sanitary Pipes
G 3448 Light Gauge Stainless Steel Tubes for Ordinary Piping
G 3459 Stainless Steel Pipes
G 3468 Large Diameter Welded Stainless Steel Pipes
G 3463 Stainless Steel Boiler and Heat Exchanger Tubes
G 3446 Stainless Steel Pipes for Machine and Structural Purposes
GOST
GOST 9940 Seamless stainless steel tubes, hot finished(5-273 mm)
GOST 9941 Seamless stainless steel tubes, cold and hot finished(5-273 mm)
SEW 400 Stainless steels
AD 2000-W2 Materials for pressure vessels - austenitic stainless steels
UNI 6904 Seamless tubes of special alloyed corrosion and heat resisting stainless steel
STAINLESS STEEL PIPE FITTINGS AND FLANGES
ASTM A182 / A182M Forged or Rolled Alloy Steel Pipe Flanges, Forged Fittings and Values and Parts for High Temperature Service
ASTM A403 / A403M Wrought Austenitic Stainless Steel Piping Fittings
ASTM A530 / A530M General Requirements for Specialised Carbon and Alloy Steel Pipe
ASTM A815 / A815M Wrought Ferritic, Ferritic / Austenitic and Martensitic Stainless Steel Piping Fittings
ASTM A276 Stainless and Heat Resisting Steel Bars and Shapes
ASTM A351 / A351M Steel Castings, Austenitic, for High Temperature Service
AS 2129 Flanges for Pipes, Values and Fittings
ANSI / ASME B 1.20.1 Pipe threads, general purpose (inch)
ANSI B 16.3 Malleable iron threaded fittings
ANSI B 16.5 Steel pipe flanges and flanged fittings
ANSI B 16.9 Factory made wrought steel butt welding fittings
ANSI B 16.11 Forged steel fittings wocket-welding and threaded
ANSI B 16.25 Butt-welding ends
ANSI B 16.28 Wrought steel butt welding short radius elbows and returns
Austenitic:
TP310S(0Cr25Ni20, 2520),
TP314(1Cr25Ni20Si2),
TP304(0Cr18Ni9),
TP321H(0Cr18Ni11Ti),
904L (00Cr20Ni25Mo4.5Cu,UNS N08904),
TP317L(00Cr19Ni13Mo3),
TP317(0Cr19Ni13Mo3)
TP347(0Cr18Ni11Nb)
TP347H(1Cr19Ni11Nb)
TP321(0Cr18Ni10Ti),
TP304H(1Cr18Ni9),
C4(00Cr14Ni14Si4),
316Ti(0Cr18Ni12Mo2Ti),
TP304L(00Cr19Ni10)
TP316(0Cr17Ni12Mo2),
TP316L(00Cr17Ni14Mo2),
S31254(00Cr20Ni18Mo6CuN）
Duplex:
UNSS31803 (00Cr22Ni5Mo3N SAF2205),
UNS S32304 (00Cr23Ni4N SAF2304),
UNS S32750 (00Cr25Ni7Mo4N SAF 2507)
Martensitic:TP410(1Cr13),TP420(2Cr13,3Cr13)
Ferritic:TP430(1Cr17),TP405(0Cr13Al)
Alloy: Monel 400,800/800H, Hastelloy C-276
Urea Grade: TP316L (00Cr18Ni14Mo3) S31050 (00Cr25Ni22Mo2N)
Standard: ASTM/ASME A/SA312,ASTM/ASME SA/A213,ASTM A269,ASTM A511,ASTM A789
ASTM A790,ASTM A268,ASTM A450/A450M
JIS G3459, JIS G3463, DIN 17456, DIN 17458 ,EN 10216-5, GB/T14975-2002, GB/T14976-2002, GB13296-91,GB 5310, etc.
The application fields covered Oil & Gas, Heat Exchanger, Petro-Chemical, Chemical, Shipbuilding, Pulp & Paper, Instrumentation, Automobile, and, food & Pharmaceutic, Nuclear Power Station, Off-shore Platform, Engineering, and etc.
|
Trade
Desig.
|
UNS
No.
|
Typical Composition ( % )
|
Form
|
Treatment
|
Tensile Strength MPa
|
Yield Strength (0.2% offset) MPa
|
Elonga tion %
|
Hardness
|
Description and Applications
|
|
C
|
Mn
|
Cr
|
Mo
|
Ni
|
Others
|
Min.
|
Min.
|
Min.
|
Max.
|
|
Austenitic Stainless Steels
|
|
301
|
S30100
|
0.10
|
1
|
17
|
|
7
|
|
Sheet
|
Annealed 1/4 to Full Hard
|
758
860-1275
|
276
515-965
|
60
25-9
|
202 HB
25 HRC
to 41 HRC
|
A dual purpose grade-for deep drawn components and high strength springs and panelling
|
|
302HQ
|
S30430
|
0.03
|
0.6
|
18
|
|
9
|
Cu 3.5
|
Wire
|
Annealed Lightly Drawn 4.0 min Dia.
|
485-690
520-725
|
-
|
-
|
-
|
Wire for severe cold heading applications such as cross-recess serews.
|
|
303
|
S30300
|
0.06
|
1.8
|
18
|
|
9
|
S 0.3
|
Bar
|
Annealed Cold Drawn
|
621
689
|
241
414
|
50
40
|
160 HB
228 HB
|
Free machining version for high speed repetition machining. Also available as "Ugima" 303 improved machinability bar for even higher machinability.
|
|
304
|
S30400
|
0.05
|
1.5
|
18.5
|
|
9
|
|
Plate
|
Annealed
|
515
|
205
|
40
|
92
|
Standard austenitic grade-excellent fabrication characteristics with good corrosion resistance. Also available as "Ugima" 304 improved machinability bar.
|
|
304L
|
S30403
|
0.02
|
1.5
|
18.5
|
|
9
|
|
Plate
|
Annealed
|
485
|
170
|
40
|
88 HRB
|
Low carbon version of 304 gives resistance to intergranular corrosion for heavy section welding and high temperature applications.
|
|
308L
|
S30803
|
0.02
|
1
|
19.5
|
|
10.5
|
|
|
|
|
|
|
|
Filler wire for welding 304 and similar grades.
|
|
309
|
S30900
|
0.05
|
1.5
|
23
|
|
13.5
|
|
|
|
|
|
|
|
Good corrosion resistance and good resistance to attack by hot sulphur compounds in oxidising gases. Filler for welding dissimilar metals.
|
|
310
|
S31000
|
0.08
|
1.5
|
25
|
|
20
|
|
Plate
|
Annealed
|
515
|
205
|
40
|
95 HRB
|
Good resistance to oxidation and carburising atmospheres in temperatures 850-1100°C
|
|
316
|
S31600
|
0.05
|
1
|
17
|
2
|
11
|
|
Plate
|
Annealed
|
515
|
205
|
40
|
95 HRB
|
Higher resistance than 304 to many media, particularly those containing chlorides. Also available as "Ugima" 316 improved machinability bar.
|
|
316L
|
S31603
|
0.02
|
1
|
17
|
2
|
11
|
|
Plate
Bar
|
Annealed
|
485
515
|
170
205
|
40
40
|
95 HRB
|
Low carbon version of 316 gives resistance to intergranular corrosion for heavy section welding and high temperature applications.
|
|
321
|
S32100
|
0.04
|
1
|
18
|
|
9
|
Ti 0.5
|
Sheet
|
Annealed
|
515
|
205
|
40
|
95 HRB
|
Titanium stabilized grade resists intergranular corrosion during exposure at 425-850°C. High strength in this temperature range.
|
|
347
|
S34700
|
0.04
|
1
|
18
|
|
9
|
Nb 0.7
|
Plate
|
Annealed
|
515
|
205
|
40
|
92 HRB
|
Niobium stabilized grade resists intergranular corrosion as for 321, but more commonly used as a filler for welding 321.
|
|
904L
|
N08904
|
0.02
|
1
|
20
|
4.5
|
24
|
Cu 1.5
|
Plate
|
Annealed
|
550
|
250
|
40
|
84 HRB
|
Super austenitic grade with very high corrosion resistance, particularly to sulphuric acid and warm chlorides.
|
|
2111HTR
|
S30815
|
0.08
|
0.6
|
21
|
|
11
|
N 0.16
Ce 0.06
|
Plate
|
Annealed
|
600
|
310
|
40
|
95 HRB
|
Excellent scaling and creep resistance at temperatures up to 1150°C.
|
|
4565S
|
S34565
|
0.02
|
6
|
24
|
5
|
17
|
N 0.45
|
Plate
|
Annealed
|
900
|
450
|
40
|
|
Super austenitic grade with extremely high corrosion resistance, particularly to strong acids and hot chlorides.
|
|
Ferritic Stainless Steels
|
|
3CR12
|
S41003
|
0.03
|
1
|
11.5
|
|
|
|
Plate
|
Annealed
|
460
|
300
|
20
|
160 HRB
|
"Utility" stainless steel with useful resistance to wet abrasion, and good formability and weldability.
|
|
409
|
S40900
|
0.06
|
1
|
11
|
|
|
Ti 0.4
|
Plate
|
Annealed
|
380
|
205
|
20
|
80 HRB
|
Resists atmospheric and automotive exhaust gas corrosion. Used extensively in auto exhaust systems.
|
|
430
|
S43000
|
0.03
|
|
|
|
|
| Specifications︰ | AÇO INOX
ASTM A213: Especificação padrão para tubos sem costura ferríticos e austeníticos para Caldeira, Super aquecedores e permutador de calor.
Grau: Gr. TP201, 202, 304, 309, 310, 316 – H/L/S.
ASTM A312: tubos de Aço Inoxidável, sem costura ou soldados, austeníticos para serviços de baixa temperatura.
Grau: Gr. TP304; 309; 310; 316; 317; 321 e 347. – H/L/S.
ASTM A358: tubos soldados austeníticos cromo-níquel. Tubulação de Aço Inoxidável para serviços de alta temperatura e aplicações gerais.
Grau: Gr. 304; 309; 310; 316; 317; 321 e 347. Cl.1; 2; 3; 4 e 5 – H/L/S.
ASTM A778: especificação padrão para tubos de soldados de aço inoxidável austenítico não recozido.
Grau: TP304; 316; 317; 321; 347 – L
ASTM A268: especificação padrão para tubos de aço inoxidável soldados e sem costura, ferríticos e martensítico para serviços gerais.
Grau: TP405, 409, 410, 429, 430/Ti, 439, 443, 446,
ASTM A269: especificação padrão para tubos de aço inoxidável austenítico sem costura e soldado para serviço geral.
Grau: TP304, 316, 317, 321, 347 – L/N
ASTM A270: especificação padrão para tubos sanitários de aço inoxidável soldados e sem costura austenítico e ferrítico.
Grau: TP304, 316 - L
ASTM A249: especificação padrão de tubos para caldeira, permutador de calor e condensador em aço austenítico soldado.
Grau: TP201, 202, 304, 305, 309, 310, 316 – H/L/S/N.
ASTM A554: especificação padrão para tubos mecânicos de aço inoxidável soldado.
Grau: MT301, 302, 304, 305, 309, 310, 316, 317, 321, 330, 347, 429, 430/Ti.
DUPLEX/SUPERDUPLEX
ASTM A790: tubos de Aço Inoxidável, sem costura ou soldados, ferrítico para serviços corrosivos.
Grau: Gr. UNS S31200, S31260, S31500, S31803, S32003, S32101, S32202, S32205, S32304, S32506, S32520, S32550, S32707, S32750, S32760, S32808, S32900, S32906, S32950, S33207, S39274, S39277.
ASTM A928: tubos soldados de Aço Inoxidável destinados a serviços corrosivos.
Grau: Gr. UNS S31200, S31260, S31500, S31803, S32003, S32205, S32304, S32550, S32750, S32900, S32950, S32760, S32520. |
| Standard Met︰ | O.D. W/T Weight
inch mm. Sch. mm. inch. Kg/m. Lb/ft.
14" 355.6 10 6.35 0.250 55.25 37.13
14" 355.6 20 7.92 0.312 68.60 46.1
14" 355.6 8.74 0.344 75.52 50.75
14" 355.6 STD-30 9.53 0.375 82.16 55.21
14" 355.6 10.31 0.406 88.68 59.59
14" 355.6 40 11.13 0.438 95.51 64.18
14" 355.6 XS 12.70 0.500 108.48 72.90
14" 355.6 14.27 0.562 121.33 81.53
14" 355.6 60 15.09 0.594 128.00 86.01
14" 355.6 80 19.05 0.750 159.71 107.32
14" 355.6 100 23.83 0.938 196.94 132.34
14" 355.6 25.40 1.000 208.92 140.39
14" 355.6 26.97 1.062 220.78 148.36
14" 355.6 120 27.79 1.094 226.93 152.49
14" 355.6 140 31.75 1.250 256.13 172.11
14" 355.6 160 35.71 1.406 284.56 191.21
16" 406.4 10 6.35 0.250 63.28 42.52
16" 406.4 7.14 0.281 71.01 47.72
16" 406.4 20 7.92 0.312 78.62 52.83
16" 406.4 8.74 0.344 86.58 58.18
16" 406.4 STD-30 9.53 0.357 94.21 63.31
16" 406.4 10.31 0.406 101.72 68.36
16" 406.4 11.13 0.438 109.59 73.64
16" 406.4 XS-40 12.700.500 124.55 83.69
16" 406.4 14.27 0.562 139.39 93.67
16" 406.4 15.88 0.625 154.48 103.80
16" 406.4 60 16.66 0.656 161.74 108.69
16" 406.4 17.48 0.688 169.35 113.80
16" 406.4 19.05 0.750 183.81 123.52
16" 406.4 20.62 0.812 198.15 133.15
16" 406.4 80 21.44 0.844 205.60 138.15
16" 406.4 25.40 1.000 241.06 161.98
16" 406.4 100 26.19 1.031 248.05 166.68
16" 406.4 120 30.96 1.219 289.54 194.56
16" 406.4 31.75 1.250 296.31 199.11
16" 406.4 140 36.53 1.438 336.57 226.16
16" 406.4 160 40.49 1.594 369.06 247.99
18" 457 20 7.92 0.312 88.60 59.54
18" 457 8.74 0.344 97.59 65.58
18" 457 STD 9.53 0.375 106.23 71.38
18" 457 10.31 0.406 114.72 77.09
18" 457 30 11.13 0.438 123.62 83.07
18" 457 XS 12.70 0.500 140.56 94.45
18" 457 40 14.27 0.562 157.38 105.75
18" 457 15.88 0.625 174.50 117.25
18" 457 17.48 0.688 191.38 128.60
18" 457 60 19.05 0.750 207.82 139.65
18" 457 80 23.83 0.938 257.13 172.78
18" 457 25.40 1.000 273.08 183.50
18" 457 26.97 1.062 288.91 194.14
18" 457 28.58 1.125 305.01 204.96
18" 457 100 29.36 1.156 312.76 210.16
18" 457 30.18 1.188 320.88 215.62
18" 457 31.75 1.250 336.33 226.00
18" 457 120 34.93 1.375 367.25 246.78
18" 457 140 39.67 1.562 412.40 277.12
18" 457 160 45.24 1.781 464.03 311.81
20" 508 8.74 0.344 108.70 73.04
20" 508 STD-20 9.53 0.375 118.33 79.51
20" 508 10.31 0.406 127.82 85.89
20" 508 11.13 0.438 137.76 92.57
20" 508 XS-30 12.70 0.500 156.70 105.3
20" 508 14.27 0.562 175.51 117.94
20" 508 40 15.09 0.594 185.28 124.50
20" 508 15.88 0.625 194.67 130.81
20" 508 17.48 0.688 213.59 143.53
20" 508 19.05 0.750 232.03 155.92
20" 508 60 20.62 0.812 250.34 168.22
20" 508 25.40 1.000 305.35 205.18
20" 508 80 26.19 1.031 314.33 211.22
20" 508 30.18 1.188 359.22 241.38
20" 508 31.75 1.250 376.66 253.10
20" 508 100 32.54 1.281 385.40 258.97
20" 508 120 38.10 1.500 445.97 299.67
20" 508 140 44.45 1.750 513.27 344.90
20" 508 160 50.01 1.969 570.54 383.38
22" 559 8.74 0.344 119.80 80.5
22" 559 STD-20 9.53 0.375 130.44 87.65
22" 559 XS-30 12.70 0.500 172.83 116.14
22" 559 15.88 0.625 214.84 144.37
22" 559 17.48 0.688 235.79 158.44
22" 559 19.05 0.750 256.23 172.18
22" 559 20.62 0.812 276.54 185.83
24" 610 8.74 0.344 130.90 87.96
24" 610 STD-20 9.53 0.375 142.55 95.79
24" 610 XS 12.70 0.500 188.96 126.98
24" 610 30 14.27 0.562 211.76 142.30
24" 610 15.88 0.625 233.02 157.93
24" 610 40 17.48 0.688 258.00 173.37
|
|
|
Product Image
|
|
|
Related Products
|
|
