API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe

  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
  • API 5L,ISO 3183,DNV OS-F101 ,EN10208-2,DEP 31.40.20.30 Seamless Line Pipe
Model No.︰API 5L/NACE
Brand Name︰API 5L/ASTM A53 B/ASTM A106 B/NACE MR0175
Country of Origin︰-
Unit Price︰US $ 1050 / MT
Minimum Order︰200 MT
Share on:

 Total 22 Related Items
Prev12345Next

Product Description
Nominal Outside Schedule
Diameter Diameter
mm inch mm inch 20 30 STD 40 60 XS 80 100 120 140 160 XXS
50 2 60.3 2.375     3.91 3.91   5.54 5.54       8.74 11.07
5.44 5.44 7.48 7.48 11.11 13.44
65 2.5 73 2.875     5.16 5.16   7.01 7.01       9.53 14.02
8.63 8.63 11.41 11.41 14.92 20.39
80 3 88.9 3.5     5.49 5.49   7.62 7.62       11.13 15.24
11.29 11.29 15.27 15.27 21.35 27.68
90 3.5 101.6 4     5.74 5.74   8.08 8.08
13.57 13.57 18.63 18.63
100 4 114.3 4.5     6.02 6.02   8.56 8.56   11.13   13.49 17.12
16.07 16.07 22.32 22.32 28.32 33.54 41.03
125 5 141.3 5.563     6.55 6.55   9.53 9.53   12.7   15.88 19.05
21.77 21.77 30.97 30.97 40.28 49.11 57.43
150 6 168.3 6.625     7.11 7.11   10.97 10.97   14.27   18.26 21.95
28.26 28.26 42.56 42.56 54.2 67.56 79.22
200 8 219.1 8.625 6.35 7.04 8.18 8.18 10.31 12.7 12.7 15.09 18.26 20.62 23.01 22.23
33.31 36.81 42.55 42.55 53.08 64.64 64.64 75.92 90.44 100.92 111.27 107.92
250 10 273.1 10.75 6.35 7.8 9.27 9.27 12.7 12.7 15.09 18.26 21.44 25.4 28.58 25.4
41.77 51.03 60.31 60.31 81.55 81.55 96.01 114.75 133.06 155.15 172.33 155.15
300 12 323.9 12.75 6.35 8.38 9.53 10.31 14.27 12.8 17.48 21.44 25.4 28.58 33.32 25.4
49.73 65.2 73.88 79.73 108.96 97.46 132.08 159.91 186.97 208.14 238.76 186.97
350 14 355.6 14 7.92 9.53 9.53 11.13 15.09 12.7 19.05 23.83 27.79 31.75 35.71
67.9 81.33 81.33 94.55 126.71 107.39 158.1 194.96 224.65 253.56 281.7
400 16 406.4 16 7.92 9.53 9.53 12.7 16.66 12.7 21.44 26.19 30.96 36.53 40.49
77.83 93.27 93.27 123.3 160.12 123.3 203.53 245.56 286.64 333.19 365.35
450 18 457.2 18 7.92 11.13 9.53 14.27 19.05 12.7 23.88 29.36 34.93 39.67 45.24
87.71 122.38 105.16 155.8 205.74 139.15 254.55 309.62 363.56 408.26 459.37
500 20 508 20 9.53 117.15 12.70 155.12 9.53 117.15 15.09 183.42 20.62 247.83 12.70 155.12 26.19 311.17 32.54 381.53 38.10 441.49 44.45 508.11 50.01 564.81
550 22 558.8 22 9.53 129.13 12.70 171.09 9.53 129.13   22.23 294.25 12.70 171.09 28.58 373.83 34.93 451.42 41.28 527.02 47.63 600.63 53.98 672.26
600 24 609.6 24 9.53 141.12 14.27 209.64 9.53 141.12 17.48 255.41 24.61 355.26 12.70 187.06 30.96 442.08 38.89 547.71 46.02 640.03 52.37 720.15 59.54 808.22
650 26 660.4 26 12.70 202.72   9.53 152.87     12.70 202.72
700 28 711.2 28 12.70 218.69 15.88 271.21 9.53 164.85     12.70 218.69
unit: -Wall Thickness(mm)
-Weight(kg/m)


1. Line Pipes
API 5L PSL1/PSL 2 Line Pipe: Gr. B X42, X46, X52, X56, X60, X65, X70, X80/BM.X42M,X46M,X52M,X60M,X65M,X70,X80M
ISO 3183-1/2 Petroleum and Natural Gas Industries-Steel Pipe for Pipelines Transportation System-L240M,L290M,L320M,L360M,L390M,L415M,L450M,L485M,L555M,L690M
ISO 3183-3 Petroleum and Natural Gas Industries Steel Pipe for Pipelines Transportation System -L245NC / L245NCS,L290NC / L290NCS, L360NC / L360NCS, L290MC / L290MCS, L360MC / L360MCS, L415MC / L415MCS, L450MC / L450MCS, L485MC / L485MCS, L555MC
AS2885 Pipelines-Gas and liquid petroleum Part 1: Design and Construction
BS 3601-1 Carbon steel pipes and tubes with specified room temperature properties for pressure purposes
BS 3602-2 Specification for steel pipes and tubes for pressure purposes: carbon and carbon manganese steel with specified elevated temperature properties. Part 2: Submerged arc welded tubes
BS 6323 Seamless and welded steel tubes for automobile mechanical and general engineering purposes. Part 1: General requirements. Part 7: Specific requirements for submerged arc welded steel tube
CSA Z245.1   Steel Pipe
DIN 2470-1 Steel gas pipelines for permissible service pressures up to 16 bar
DIN 2470-2 Steel gas pipelines for permissible service pressures exceeding 16 bar
EN 10208-1:2009, Steel pipes for pipelines for combustible fluids - Technical delivery conditions - Part 1: Pipes of requirement class A.
EN 10208-2:2009, Steel pipes for pipelines for combustible fluids – Technical delivery conditions – Part 2: Pipes of requirement class B. L245MB,L290MB,L320MB,L360MB,L390MB,L415MB,L450MB, L485MB,L555MB
EN 10208-3  Non alloy and alloy fine grain steel tubes
EN ISO 21329:2004, Petroleum and natural gas industries - Pipeline transportation systems - Testing procedures for mechanical connections (ISO 21329:2004).
ISO 10543:1993, Seamless and hot-stretch-reduced welded steel tubes for pressure purposes - Full peripheral ultrasonic thickness testing.
ISO 21329:2004, Petroleum and natural gas industries - Pipeline transportation systems - Testing procedures for mechanical connections. - 1st edition.
EEMUA Publ 203:2004, Guide to the Application of ISO 3183 Parts 2 (1996) and 3 (1999) Petroleum and Natural Gas Industries - Steel Pipes for Pipelines - Technical Delivery Conditions.
NACE MR 0175/ISO 15156-2  Petroleum and Natural Gas Industries – Materials for Use in H2S Containing Environments in Oil and Gas Production. Part 2. Cracking resistant Carbon and Low Alloy Steels, and the Use of Cast Irons.
NACE TM 0177 Laboratory Testing of Metals for Resistance to Sulfide Stress Cracking in Hydrogen Sulfide (H2S) Environments
NACE TM 0284 Standard Test Method - Evaluation of Pipeline and Pressure Vessel Steels for Resistance to Hydrogen-Induced Cracking

DEP 31.40.20.30-Gen LINEPIPE FOR USE IN OIL AND GAS OPERATIONS UNDER NON-SOUR CONDITIONS(AMENDMENTS/SUPPLEMENTS TO API SPEC 5L)
DEP 31.40.20.31-Gen LINEPIPE FOR USE IN OIL AND GAS OPERATIONS UNDER SOUR CONDITIONS(AMENDMENTS/SUPPLEMENTS TO API SPEC 5L)
DEP 31.40.20.35-Gen Line pipe for non-critical service (amendments/supplements to ISO 3183-1)
DEP 31.40.20.37-Gen Linepipe for critical service (amendments/supplements to ISO 3183-3)
DEP 31.40.40.38-Gen Hydrostatic pressure testing of new pipelines
DEP 31.40.60.11-Gen Pipeline leak detection
DEP 31.40.60.12-Gen Pipeline Repairs (supplements to ANSI/ASME B31.4 and B31.8)
DEP 61.40.20.30-Gen Welding of pipelines and related facilities (amendments/supplements to ANSI/API STD 1104)
DEP 31.40.50.30-Gen  Precommissioning of pipelines
NF A 49-112-Plain end seamless hot rolled tubes
GOST 8731-87 seamless hot-deformed steel pipes-DIN 1629,ASTM A106B
GOST 8732-78 - seamless hot-deformed steel pipes,manufactured on the outside diameter, wall thickness and length.
EN 10220 DIN 1630 High-performance seamless circular - Seamless circular unalloyed steel tubessubject to spe

Specifications︰ EN 10208-1,2 Steel pipes for pipelines for combustible fluids

2. Coating Specifications
2.1.External Coating
2.1.1 External Epoxy Coating
API RP 5L2 Recommended Practice for Internal Coating of Line Pipe for Non-Corrosive Gas Transmission Service.
CAN/CSA-Z245.20 Standard for External Fusion Bond Epoxy Coating for Steel Pipe
AS 3862 Standard Specification for External Fusion-Bonded Epoxy Coating for Steel Pipes
AWWA C210 Standard for Liquid-Epoxy Coating Systems for the Interior and Exterior of Steel Water Pipelines
AWWA C213 Standard for Fusion Bonded Epoxy Coating for the Interior and Exterior of Steel Water Pipelines.
DEP 31.40.30.32-Gen TECHNICAL SPECIFICATION FOR EXTERNAL FUSION-BONDED EPOXY POWDER COATINGFOR LINE PIPE
NFA 49-710 Standard Specification for External FBE layered Coating
ISO 21809-2:2007, Petroleum and natural gas industries-External coatings for buried or submerged pipelines used in pipeline transportation systems-Part 2: Fusion-bonded epoxy coatings
NACE RP0394 – National Association of Corrosion Engineers Standard Recommended Practice, Application, Performance, and Quality Control of Plant Applied, Fusion Bonded Epoxy External Pipe Coating.
NACPA 12-78 – National Association of Pipe Coating Applicators External Application Procedure for Plant Applied fusion Bonded Epoxy (FBE) to Steel Pipe.
SAES-H-002 Internal and External Coatings for Steel Pipelines and Piping
09-SAMSS-089 Shop-Applied External FBE Coating
09-SAMSS-091 Shop-Applied Internal FBE Coatings

2.1.2 Polyethylene Coating
CAN/CSA Z245.21 External Polyethylene Coating for Pipe
DIN 30670 Polyethylene Sheathing of Steel Tubes and of Steel Shaped Fittings
NFA 49-710 External Three-Layer Polyethylene Based Coating, Application by Extrusion
DNV-RP-F106 Factory Applied External Pipeline Coatings For Corrosion Control
AS/NZS 1518 External Extruded High-Density Polyethylene Coating System for Pipes
ISO/DIS 21809-1 Petroleum and natural gas industries -- External coatings for buried or submerged pipelines used in pipeline transportation systems - Part 1: Polyolefin coatings (3- layer PE and 3- layer PP)
ISO 21809-4:2009, Petroleum and natural gas industries -External coatings for buried or submerged pipelines used in pipeline transportation systems-Part 4: Polyethylene Coatings (2-layer PE)
DEP 31.40.30.31-Gen. TECHNICAL SPECIFICATION FOR EXTERNAL POLYETHYLENE AND POLYPROPYLENE COATING FOR LINE PIPE
IPS-G-TP-335 Material and Construction Standard for Three Layer Polyethylene Coating System
NFA 49-710 External 3 layer Polyethylene Coating
PETROBRAS' ET-200.03 Engineering Specification ("Piping Materials for Production and Process Facilities") for using low density linear polyethylene in carbon steel piping, as to appendix 13 of such specification.
09-SAMSS-113 External Renovation Coating for Buried Pipelines and Piping (APCS-113)
UNI 9099-DIN 30670 Polyethylene Coating Applied by Extrusion

2.1.3 Polypropylene Coating
DIN30678 Polypropylene Sheathing of Steel Tubes and of Steel Shaped Fittings
EN 10286 Steel tubes and fittings for onshore and offshore pipelines –External three layer extruded polypropylene based coatings.
NFA 49-711 External Three-Layer Polypropylene Based Coating, Application by Extrusion
09-SAMSS-114 Shop-Applied Extruded, Three-Layer Polypropylene External Coatings for Line Pipe

2.1.4 Polyurethane Coating
AWWA C222-99: Polyurethane Coatings for the Interior and Exterior of Steel Water Pipe and Fittings
BS 5493- Polyurethane Coating
DIN 30677.2 polyurethane Insulation of the fittings
EN 10290- External Liquid Applied Polyurethane Coatings

2.1.5 Polyolefin Coating
AWWA C225-03: Fused Polyolefin Coating Systems for the Exterior of Steel Water Pipelines
AWWA C215-99: Extruded Polyolefin Coatings for the Exterior of Steel Water Pipelines
AWWA C216-00 Standard for Heat-Shrinkable Cross-Linked Polyolefin Coatings for the Exterior of Special Sections, Connections, and Fitting for the Steel Water Pipelines
AWWA C224 - 01: Two-layer Nylon-11 Based Polyamide Coating System for Interior and Exterior of Steel Water Pipe and Fittings
AWWA C225 - 03: Fused Polyolefin Coating Systems for the Exterior of Steel Water Pipelines

2.1.6 Tape Coating
ISO 21809-3:2008, Petroleum and natural gas industries-External coatings for buried or submerged pipelines used in pipeline transportation systems-Part 3: Field joint coatings
AWWA C209-00: Standard for Cold-Applied Tape Coatings for the Exterior of Special Sections, Connections, and Fittings for Steel Water Pipelines
AWWA C214-00 Standard for Tape Coating Systems for the Exterior of the Steel Water Pipelines
AWWA C217-99 Standard for Cold-Applied Petrolatum Tape and Petroleum Wax Tape Coatings for the Exterior for Special Sections, Connections, and Fittings for Buried/Submerged Steel Water Pipelines
AWWA C218-02 Standard for Coating the Exterior of Aboveground Steel Water Pipelines and Fittings
AWWA C224-01: Two-layer Nylon-11 Based Polyamide Coating System for Interior and Exterior of Steel Water Pipe and Fittings
EN 12068 - DIN 30672 STANDARD-POLYETHYLENE SELF ADHESIVE TAPES

2.1.7 Bitumen Coating
DIN 30673 Bitumen coatings and linings for steel pipes, fittings and vessels.

2.1.8 Coal-Tar Enamel Coating
AWWA C-203 Coal-Tar Protective Coatings and Linings for Steel Water Pipelines-Enamel and Tape-Hot-Applied
AWWA C205 Cement Mortar Protective Lining and Coating for Steel Water Pipe - 4 inch (100 mm) and Larger- Shop Applied

2.1.9 Concrete Weighted Coating
DNV-OS-F101 Submarine Pipeline System
ASTM C171 Specification for Sheet Material for Coating Concrete
BS EN 12620 Aggregates for Concrete
ISO 21809-5:2009, Petroleum and natural gas industries -External coatings for buried or submerged pipelines used in pipeline transportation systems - Part 5:External concrete coating.
ASTM C42 Standard Test Method for Obtaining and Testing Drilled Cores and Sawed Beams of Concrete
ASTM C642 Standard Test Method for Specific Gravity, Absorption and Voids in Hardened Concrete
ASTM C87 Standard Test Method for Effect of Impurities in Fine Aggregate on Strength of Mortar BS 1881 Methods of Testing Concrete
BS 3148 Methods of Test for Water for Making Concrete
BS 4482 Hard Drawn Mild Steel Wire for the Reinforcement of Concrete
BS 4483 Specification for Steel Fabric for the Reinforcement of Concrete
BS 4449 Specification for Carbon Steel Bars for Reinforcement of Concrete
ISO 4012 Determination of Compressive Strength of Test Specimen

2.1.10 Marine Coating
EN ISO 12944:1998 – Paints & Varnishes – Corrosion Protection of Steel Structures by protective paint system (parts 1 – 8)
ISO 20340:2009 Paints and varnishes – Performance requirements for protective paint systems for offshore and related structures
ISO 15741 Paints and varnishes-Friction-reduction coatings for the interior of on- and offshore pipelines for non-corrosive gases

2.1.11 Other specification
British Gas BGC/PS/CM1,
BGC/PWS/CM2
GAZ de France R 09
NACE RP 0181
NF A 49-706
TS 5140
TS 5139,

2.2. Lining

2.2.1 Epoxy Lining
AWWA C210: Liquid-Epoxy Coating Systems for the Interior and Exterior of Steel Water Pipelines
API RP512 or NFA 49-709 Internal can be epoxy 80 microns
TS EN 10289
NFA 49708 Recommended Practice for Internal Coating of Line Pipe

2.2.2 Bitumen Lining
DIN 30673 Bitumen coatings and linings for steel pipes, fittings and vessels
UNI-ISO 5256/87 STANDARD-BITUMEN COATING

2.2.3 Cement Mortar Lining
AS/NZS 1516 Cement Mortar Lining of Pipelines In Situ
AWWA C203-02: Coal-Tar Protective Coatings & Linings for Steel Water Pipelines, Enamel & Tape, Hot-pap. (Incl. add. C203a-99)
AWWA C205-00: Cement-Mortar Protective Lining and Coating for Steel Water Pipe- 4 In. (100 mm) and Larger-Shop application
AWWA C602 Standard for Cement-Mortar Lining of Water Pipelines - 4 inch (100 mm) and Larger - In Place

2.2.4 Shop Cement Lined Piping
AWWA C205,C104,C602
DIN 2614
British Standard BS 534
British Petroleum GS 106-1
Shell DEP 30.48.30.31-Gen.
Saudi Aramco 01-SAMSS-005
KNPC ENG STD 87C1
API RP 10E
Standard Met︰7305.20.00 CONDUCTOR CASING, OILWELL, to API specification 5L, with OR without connectors, having BOTH of the following:
(a) outside diameter exceeding 500 mm;
(b) wall thickness exceeding 20 mm
Product Image











Related Products
API 5L X42 X46 X52 X56 X60 X65,DNV OS-F101,NACE MR0175-Seamless Line Pipe
API 5L X42 X46 X52 X56 X60 X65,DNV OS-F101,NACE MR0175-Seamless Line Pipe
US $ 850
API 5LPSL 3, IPS-M-PI-190, ISO 3183-3, EN 10210 Seamless Pipe
API 5LPSL 3, IPS-M-PI-190, ISO 3183-3, EN 10210 Seamless Pipe
US $ 850
ASTM A106/ASTM A179,ASTM A192,ASTM A209,ASTM 210,ASTM A213,EN10216 Boiler Tube
ASTM A106/ASTM A179,ASTM A192,ASTM A209,ASTM 210,ASTM A213,EN10216 Boiler Tube
US $ 785
ASTM A213/ASME SA21 T5,T9,T11,T22,T23, T91,T92/DIN 17175 Heat Exchanger Tube
ASTM A213 T5,T9,T11,T22,T23, T91,T92/DIN 17175/DIN 10216-2 Heat Exchanger Tube
US $ 885

Company Profile  |  Products  |  Reference List  |  Association Membership  |  Inspection Report  |  Quality Policy  |  HSE  |  EPCM  |  News  |  Pipe Specs  |  CS Pipe Specs  |  Stainless Steel Specs  |  API Specs  |  EN & DIN Specification  |  Australian Standard  |  GOST Specification  |  Corrosion Protection  |  Steel Plate Specs  |  Fittings Specs  |  Fasteners Specs  |  Contact Us  |  Sitemap  |  Mobile Version
  English     简体版     繁體版
Powered by DIYTrade.com
HomeContact UsSitemap
